[2] REMOVING OF MAJOR PARTS (LC-70LE650U/C6500U/LE657U)
1. Removing of Stand Unit and Rear Cabinet Ass’y.
1. Remove the 4 lock screws and detach the Stand Unit .
2. Remove the 1 lock screw and detach the AC Cord Cover .
3. Disconnect AC wire and detach the AC Cord .
4. Remove the 9 lock screws and 21 lock screws and detach the Rear Cabinet Ass’y .
