LC-60/70LE600U
4 – 10
3. Removing of Connectors
1. Disconnect the following connectors from the MAIN Unit. (PD, LW, Cl)
2. Disconnect the following connectors from the POWER/DRIVER Unit. (PD, LA)
3. Disconnect the following connectors from the LCD CONTROL Unit. (LV, PL)
䎾䎳䎧䏀
䎯䎦䎧䎃䎦䎲䎱䎷䎵䎲䎯䎃䎸䏑䏌䏗
䎰䎤䎬䎱䎃䎸䏑䏌䏗
䎳䎲䎺䎨䎵䎒䎧䎵䎬䎹䎨䎵䎃䎸䏑䏌䏗
䎾䎳䎯䏀
䎾䎯䎹䏀
MAIN Unit
[PD]
[CI]
[LW]
䎾䎯䎤䏀
