LC-60/70LE650U/C6500U/LE657U,LC-60/70LE755U/LE757U/LE857U/C7500U
4 – 24
2. Removing of Bottom cover, Speaker(L/R), KEY Unit Ass'y.
1. Remove the 1 lock screw and the 4 Hooks and detach the Bottom Cover .
2. Detach the Speaker (L) , Speaker (R) .
3. Detach the KEY Unit Ass'y .
4. Remove the 2 Hooks and detach the Key Button from the Key Button Cover .
5. Disconnect the KM wire.
6. Detach the KEY Unit from Key Button .
Hook
Hook
Ԙ
ԙBottom Cover
Ԛ
Speaker (L)
ԛ
Speaker (R)
Ԝ-';7PKV#UU[
ԝ-G[$WVVQP
ԟ-G[$WVVQP
˴%QXGT
㨇-/?
Ԟ-';7PKV
SP
*QQM
