LC-40LE830U
Service Manual
OUTLINE
MAJOR SERVICE PARTS
PWB Unit
NOTE: *1 Replace MAIN PWB Units (DKEYMF733FM**) in case of IC8401, IC3303 or IC8455 failure.
*2 Touch Sensor Unit reuse will be impossible, once it is stuck on front Cabinet and exfoliates.
OTHER Unit
IC For Exclusive Use Of The Service
Ref No. Parts No. Description
N DKEYMF733FM16 MAIN Unit (LC-40LE835U)
N DKEYMF733FM14 MAIN Unit (LC-46LE835U)
N DKEYMF733FM13 MAIN Unit (LC-52LE835U)
N DKEYMF733FM12 MAIN Unit (LC-60LE835U)
N DKEYMF733FM04 MAIN Unit (LC-40LE830U)
N DKEYMF733FM03 MAIN Unit (LC-46LE830U)
N DKEYMF733FM02 MAIN Unit (LC-52LE830U)
N DKEYMF733FM01 MAIN Unit (LC-60LE830U)
N DKEYMF733FM18 MAIN Unit (LC-60LE831U)
N DKEYMF733FM10 MAIN Unit (LC-40LE832U)
N DKEYMF733FM08 MAIN Unit (LC-46LE832U)
N DKEYMF733FM07 MAIN Unit (LC-52LE832U)
N DKEYMF733FM06 MAIN Unit (LC-60LE832U)
N DUNTKF494FM01 R/C, Operation Unit
N DUNTKF770FM03 ICON Unit (LC-40/46/52/60LE835U)
N DUNTKF770FM02 ICON Unit (LC-40/46/52/60LE830U/832U/LC-60LE831U)
N RUNTKA810WJQZ WiFi Unit
N RUNTKA811WJQZ Touch Sensor Unit (LC-40/46/52/60LE835U)
N RUNTKA812WJQZ Touch Sensor Unit (LC-40/46/52/60LE830U/832U/LC-60LE831U)
N RUNTKA819WJQZ IR Emitter Unit (LC-40/46/52/60LE835U Only)
N RUNTKA786WJQZ POWER/LED Drive Unit (LC-40LE835U/830U/832U)
N RUNTKA790WJQZ POWER/LED Drive Unit (LC-46LE835U/830U/832U)
N RUNTKA794WJQZ POWER/LED Drive Unit (LC-52LE835U/830U/832U)
N RUNTKA798WJQZ POWER/LED Drive Unit (LC-60LE835U/830U/831U/832U)
N RUNTK4909TPZS LCD Control Unit (LC-40LE835U)
N RUNTK4909TPZW LCD Control Unit (LC-46LE835U)
N RUNTK4909TPZF LCD Control Unit (LC-52LE835U)
N RUNTK4909TPZA LCD Control Unit (LC-60LE835U)
N RUNTK4910TPZE LCD Control Unit (LC-40LE830U/832U)
N RUNTK4910TPZC LCD Control Unit (LC-46LE830U/832U)
N RUNTK4910TPZB LCD Control Unit (LC-52LE830U/832U)
N RUNTK4910TPZZ LCD Control Unit (LC-60LE830U/831U/832U)
Ref No. Parts No. Description
N R1LK400D3GW50Z 40" LCD Panel Module Unit (LK400D3GW50Z) (LC-40LE835U)
N R1LK460D3GW40Z 46" LCD Panel Module Unit (LK460D3GW40Z) (LC-46LE835U)
N R1LK520D3GW40Z 52" LCD Panel Module Unit (LK520D3GW40Z) (LC-52LE835U)
N R1LK600D3GW40Z 60" LCD Panel Module Unit (LK600D3GW40Z) (LC-60LE835U)
N R1LK400D3GW80Z 40" LCD Panel Module Unit (LK400D3GW80Z) (LC-40LE830U/832U)
N R1LK460D3GW80Z 46" LCD Panel Module Unit (LK460D3GW80Z) (LC-46LE830U/832U)
N R1LK520D3GW80Z 52" LCD Panel Module Unit (LK520D3GW80Z) (LC-52LE830U/832U)
N R1LK600D3GW30Z 60" LCD Panel Module Unit (LK600D3GW30Z) (LC-60LE830U/831U/832U)
Ref No. Parts No. Description Q'ty
IC2001 RH-iXD241WJN1Q IC R5F21368CNFP (Monitor Microcomputer) 1
