LC-40/46/52/60LE835U/830U/832U/LC-60LE831U
6
NO. PARTS CODE
PRICE
RANK
NEW
MARK
PART
DELIVERY
DESCRIPTION
[4] CABINET PARTS (LC-46LE835U/830U/832U)
1 CCABAC654WJ31 BK N X Front Cabinet Ass'y (LC-46LE835U)
1 CCABAC654WJ32 BF N X Front Cabinet Ass'y (LC-46LE830U)
1 CCABAC654WJ33 BF N X Front Cabinet Ass'y (LC-46LE832U)
1-1 Not Available - N - Front Cabinet
1-2 Not Available - N - R/C Operation Cover
1-3 HDECQB540WJ3A AX N X Front Decoration (LC-46LE835U)
1-3 HDECQB604WJ3A AX N X Front Decoration (LC-46LE830U)
1-3 HDECQB604WJ3B AX N X Front Decoration (LC-46LE832U)
1-4 LHLDWA133WJKZ AC J Wire Holder
1-5 Not Available - N - Sheet
1-6 TLABZC680WJZZ AB N X Quattron 3D Label
1-6 TLABZC585WJZZ AF J Quattron Label
1-7 TLABZC778WJZZ AA N X WiFi Label
2 CCABBB886WJ31 BD N X Rear Cabinet Ass'y
2-1 Not Available - N - Rear Cabinet
2-2 HiNDPE029WJSA AF N X Terminal Label (Length)
2-3 HiNDPE031WJSA AE N X Terminal Label (Width)
2-4 HiNDPE034WJSA AD N X Terminal Label (Back)
3 HDECPA090WJZZ AC N X Decoration Sheet (Side)
4 HDECPA091WJZZ AB N X Decoration Sheet (Bottom)
5 LANGKD120WJM1 AK N X Center Angle, x2
6 LANGKD146WJFW AD N X Terminal Angle Bottom
7 LHLDWA133WJKZ AC J Wire Holder, x2
8 LHLDWA138WJKZ AC J Wire Holder, x2
9 LHLDWA175WJUZ AC J Wire Holder, x9
10 LHLDWA176WJUZ AC J Wire Holder
11 LX-BZA207WJF7 AA J Screw, x20
12 PSLDMB748WJFW AH N X Main PWB Shield
13 PSPAZC690WJZZ AC N X Spacer
14 PSPAZC691WJZZ AB N X Spacer, x3
15 PSPAZC702WJKZ AH N X Spacer
16 PZETKA580WJKZ AN N X Insulator Sheet
17 QCNW-L590WJQZ AN N X Connecting Cord (PD:MAIN-POW)
18 QCNW-L596WJQZ AE N X
Connecting Cord (PL:MAIN-LCDCTL)
19 QCNW-L618WJQZ AF N X Connecting Cord (SB:MAIN-WOOFER)
20 QCNW-L628WJQZ AR N X Connecting Cord (LW:MAIN-LCDCTL) (LC-46LE835U)
20 QCNW-L719WJQZ N X Connecting Cord (LV:MAIN-LCDCTL) (LC-46LE830U/832U)
21 QCNWN2733TPZZ AE N X Connecting Cord (80P:MDL-CTL), x2
22 QCNWN2734TPZZ AE N X Connecting Cord (64P:MDL-CTL), x2
23 RCORFA061WJZZ AG J Core, x4
24 XBPS830P06WS0 AA J Screw, x12
25 GCOVAC576WJKZ AC J Vesa Hole Cover, x4
26 GCOVAD969WJ3A AC N X AC Cord Cover
27 GCOVAD973WJ3A AD N X Bottom Cover
28 HiNDPE023WJSA AB N X Model Label (LC-46LE835U)
28 HiNDPE055WJSA AB N X Model Label (LC-46LE830U)
28 HiNDPE065WJSA AB N X Model Label (LC-46LE832U)
29 LANGKD124WJM1 AS N X Stand TCON Angle
30 LANGKD127WJFW AA N X Fixing Metal Angle, x9
31 LHLDWA303WJKA AE J Cable Clamp
32 PSPAZC062WJKZ AG J Spacer
!
33 QACCDA084WJPZ AH N X AC Cord
34 QCNW-L582WJQZ AD N X Connecting Cord (RA:KEY-R/C)
35 QCNW-L592WJQZ AF N X Connecting Cord (CI:MAN-EMBLEM)
36 QCNW-L595WJQZ AG N X Connecting Cord (SP:MAIN-SP(L/R))
37 QCNW-L597WJQZ AH N X Connecting Cord (UB:MAIN-WIFI)
38 QCNW-L598WJQZ AT N X Connecting Cord (RC:MAIN-KEY/IR) (LC-40LE835U)
38 QCNW-L722WJQZ AP N X Connecting Cord (RC:MAIN-KEY) (LC-40LE830U/832U)
39 RSP-ZA511WJQZ AR N X Speaker (L/R), x2
40 RSP-ZA513WJQZ AV N X Speaker (Sub Woofer)
41 XBPS830P06WS0 AA J Screw, x21
42 XEBS830P08000 AA J Screw
43 XEBS830P12000 AA J Screw, x5
44 TLABNB037WJZZ AB N X Serial Label (Back)
45 Not Available - N - Serial Label (Side)
46 LHLDWA175WJUZ AC J Wire Holder
47 PZETKA605WJKZ AG N X Insulation Sheet
48 LX-BZA401WJN1 AB N X Screw, x2
