LC-60/70LE650U/C6500U/LE657U,LC-60/70LE755U/LE757U/LE857U/C7500U
4 – 3
2. Removing of Speaker (L/R), KEY Unit and Bottom Cover.
1. Remove the 2 lock screws and detach the Speaker (L) , Speaker (R) .
2. Disconnect the SP wire.
3. Disconnect the RC wire.
4. Detach the KEY Unit Ass’y .
5. Disconnect the KM wire.
6. Remove the 2 Hooks and detach the KEY Unit from Key Button .
7. Remove the 1 lock screw , 6 Hooks and detach the Bottom Cover-R and Bottom Cover-L .
8. Remove the 1 lock screw and detach the Wi-Fi Hoder .
9. Detach the Wi-Fi Unit from Wi-Fi Holder .
10.Disconnect the UB wire.
11.Detach the BLUETOOTH Unit from Bottom Cover-R .(LC-60LE657U Only)
12.Disconnect the BT wire.(LC-60LE657U Only)
LA
PD
LV
l
PL
LV
UB
䎫䏒䏒䏎
䎾䎶䎳䏀
䎶䏓䏈䏄䏎䏈䏕䎃䎋䎵䎌
䎶䏓䏈䏄䏎䏈䏕䎃䎋䎯䎌
䎥䏒䏗䏗䏒䏐䎃
䎦䏒䏙䏈䏕䎐䎵
䎥䏒䏗䏗䏒䏐
䎦䏒䏙䏈䏕䎐䎯
䎛
䎜
䎔䎔
䎕
䎔䎓
䎔
䎰䎤䎬䎱䎃䎸䏑䏌䏗
䎫䏒䏒䏎 䎫䏒䏒䏎
[SP]
[RC]
䎔䎓
[KM]
6
3
5 Key Button
KEY Unit
KEY Unit
Ass'y
䎺䏌䎐䎩䏌䎃䎸䏑䏌䏗䎺䏌䎐䎩䏌䎃䎸䏑䏌䏗
䎺䏌䎐䎩䏌䎃䎫䏒䏏䏇䏈䏕䎺䏌䎐䎩䏌䎃䎫䏒䏏䏇䏈䏕
䎾䎸䎥䏀䎾䎸䎥䏀
䎔䎕
䎔䎖
䎔䎗
䎔䎘
䎥䎯䎸䎨䎷䎲䎲䎷䎫䎃
䎸䏑䏌䏗
䎥䎯䎸䎨䎷䎲䎲䎷䎫䎃
䎸䏑䏌䏗
䎾䎥䎷䏀䎾䎥䎷䏀
