Sharp LC-90LE657U

PARTS GUIDE
Parts marked with " " are important for maintaining the safety of the set. Be sure to replace these
parts with specified ones for maintaining the safety and performance of the set.
This document has been published to be used
for after sales service only.
The contents are subject to change without notice.
LC-90LE657U
PartsGuide
[1] PRINTED WIRING BOARD
ASSEMBLIES
[2] DKEYMF953FM06 (MAIN Unit)
[3] DUNTKG281FM02
(LCD CONTROL Unit)
CONTENTS
No. S53B6LC90LE6P
LCD COLOR TELEVISION
LC-90LE657U
MODEL
Note:
The reference numbers on the PWB are arranged
in alphabetical order.
