LC-90LE657U
iv
LC-90LE657U
Service Manual
OUTLINE
MAJOR SERVICE PARTS
PWB Unit
NOTE: *1 Replace MAIN PWB Units (DKEYMF953FM06) in case of IC3103 failure.
OTHER Unit
IC For Exclusive Use Of The Service
Service Jigs
Ref NO. PARTS CODE DESCRIPTION
N DKEYMF953FM06 MAIN Unit
N DUNTKG281FM02 LCD CONTROL Unit
N DUNTKF800FM53 KEY Unit
N DUNTKG014FM02 ICON Unit
N DUNTKG015FM02 R/C OPC Unit
N RUNTKA936WJQZ WiFi Unit
N RUNTKB126WJQZ BLUETOOTH Unit
N RUNTKB096WJQZ POWER/DRIVER Unit
Ref NO. PARTS CODE DESCRIPTION
N R1LK900D3GW10Z 90" LCD PANEL Unit (LK900D3GW10Z)
Ref No. Parts No. Description Q’ty
IC2004 RH-iXD515WJN7Q IC (Monitor Microprocessor) 1
Ref No. PARTS CODE DESCRIPTION Q'ty
N QCNW-C222WJQZ Connecting Cord L=1000mm 80pins, LCD Control Unit to LCD Panel Unit, x2 2
N QCNW-N676WJQZ Connecting Cord L=1000mm 41pins, Main to LCD Control Unit (LV) 1
N QCNW-M539WJQZ Connecting Cord L=1200mm 24-24/4pins, Power-Main/LCD Control (PD) 1
