Sharp LC-90LE657U - Page 24

LC-90LE657U
5 – 6
7 1 ANALOG RGB ADJ Analog RGB picture level adjustment
2 R A_GAIN
3 G A_GAIN
4 B A_GAIN
5 R OFFSET
6 G OFFSET
7 B OFFSET
8 RGB_A_CLAMP
8 1 VCOM ADJ VCOM adjustment value
9 1 LEV1 Standard value 1 Adjustment gradation setting.
2 LEV2 Standard value 2
3 LEV3 Standard value 3
4 LEV4 Standard value 4
5 LEV5 Standard value 5
6 LEV6 Standard value 6
10 1 MG1R WB adjustment Point 1, R adjustment value Parameter for six-point adjustment
2 MG1G WB adjustment Point 1, G adjustment value
3 MG1B WB adjustment Point 1, B adjustment value
4 MG1Y WB adjustment Point 1, Y adjustment value Quattron panel Only
5 MG2R WB adjustment Point 2, R adjustment value
6 MG2G WB adjustment Point 2, G adjustment value
7 MG2B WB adjustment Point 2, B adjustment value
8 MG2Y WB adjustment Point 2, Y adjustment value Quattron panel Only
9 MG3R WB adjustment Point 3, R adjustment value
10 MG3G WB adjustment Point 3, G adjustment value
11 MG3B WB adjustment Point 3, B adjustment value
12 MG3Y WB adjustment Point 3, Y adjustment value Quattron panel Only
11 1 MG4R WB adjustment Point 4, R adjustment value Parameter for six-point adjustment
2 MG4G WB adjustment Point 4, G adjustment value
3 MG4B WB adjustment Point 4, B adjustment value
4 MG4Y WB adjustment Point 4, Y adjustment value Quattron panel Only
5 MG5R WB adjustment Point 5, R adjustment value
6 MG5G WB adjustment Point 5, G adjustment value
7 MG5B WB adjustment Point 5, B adjustment value
8 MG5Y WB adjustment Point 5, Y adjustment value Quattron panel Only
9 MG6R WB adjustment Point 6, R adjustment value
10 MG6G WB adjustment Point 6, G adjustment value
11 MG6B WB adjustment Point 6, B adjustment value
12 MG6Y WB adjustment Point 6, Y adjustment value Quattron panel Only
13 MG6Y OFFSET
12 1 LO R 1
2LO G 1
3LO B 1
4LO Y 1
5LO R 2
6LO G 2
7LO B 2
8LO Y 2
9LO R 3
10 LO G 3
11 LO B 3
12 LO Y 3
Page Line Item Description Remarks (adjustment detail, etc.)
