Appendix
Removing the Stand
•
Before detaching (or attaching) the stand, make sure to turn off the TV and unplug the AC cord.
CAUTION
• Do not remove the stand from the TV unless using an optional wall mount bracket to mount it.
■
LC-70C8470U/LC-70C7450U
1
Loosen the screws used to secure the stand cover.
2
1
Pull the bottom of the stand cover slightly toward
you to allow it to move upward.
2
Move the stand cover upward, and pull it toward
you to remove.
2
1
3
Unfasten the four screws used to secure the stand
in place.
4
Detach the stand from the TV.
■
LC-60C8470U/LC-60C7450U
1
1
Loosen the screws used to secure the stand cover.
2
Remove the cover.
1
2
2
Unfasten the four screws used to secure the stand
in place.
3
Detach the stand from the TV.
• In the installation procedure, be careful not to catch your fi ngers between the TV set and the
fl oor.
LC-7060C7450U8470UE08.indd83LC-7060C7450U8470UE08.indd83 2012/02/0616:01:452012/02/0616:01:45
