LC-32D47U/LC-32SB27U/LC-C3237U
2 – 1
LC32D47U
Service Manual
CHAPTER 2. OPERATION MANUAL
[1] OPERATION MANUAL
TV (Front)
*OPC: Optical Picture Control
TV (Rear/Side)
*1
*2
*3
*1
POWER
button
MENU
button
INPUT
button
Channel
buttons
(CH /)
Volume
(Except for
LC-32SB27U)
buttons
(VOL /)
DIGITAL AUDIO
OUTPUT terminal
INPUT 6 terminal
(HDMI)
INPUT 5 terminal (HDMI)
INPUT 4 terminal (PC-IN)
AUDIO terminal (shared for INPUT 4 and INPUT 5) *4
Antenna/Cable in
INPUT 1 terminals
INPUT 2 terminals
AUDIO OUTPUT
terminals
AC INPUT
terminal
INPUT 3
terminals
SERVICE
terminal
INPUT 7
terminal
(HDMI)
*1 External equipment connection.
*2 Button operations.
*3 Connecting the AC cord.
*4 Details on the PC Audio Select function.
The illustrations in this operation manual are for explanation purposes and may vary slightly from the actual operations.•
POWER indicator
OPC sensor*
Remote control sensor
