10
Product description
1. INPUT button . . . . . . . . . . . . . . To switch between the signal’s input terminals. (Analogue RGB input
terminal ↔ DVI-I input terminal)
2. MENU button . . . . . . . . . . . . . . . This button is used to pop-up, select and close the OSD (On Screen
Display) Menu.
3. SELECT button . . . . . . . . . . . . . This button is used to select menu options when the OSD Menu is
displayed.
4. buttons . . . . . . . . . . . . . . . When the OSD Menu is displayed:
These buttons are used to increase or decrease the value of a
selected option.
When the OSD Menu is not displayed:
These buttons are used to adjust backlight brightness and speaker
volume.
5. Power button
6. Power LED . . . . . . . . . . . . . . . . This LED is lit green when in use and orange when in power-saving
mode.
7. Speakers . . . . . . . . . . . . . . . . . . Audio entering via the monitor and the external device connected to
the monitor can be heard.
Adjusting the tilt and the swivel of monitor
Lightly holding both sides of the monitor, adjust it
to a suitable viewing angle.
Note:
When adjusting the screen tilt and swivel,
pressure from hands on the LCD panel could
cause damage.
approx.30°
approx.45°
approx.45°
approx.5°
