– 13 –
MD-E9000H
Figure 13-1
(H1)x1
ø2.6x10mm
(J1)x10
ø2.6x10mm
(J2)x1
(H2)x2
(H2)x1
(H2)x1
Rear
Cabinet
Top
Cabinet
CD Servo
PWB
Display
PWB
CD Lid
Open/Close
PWB
(H1)x2
ø2.6x10mm
(L1)x2
ø2.6x10mm
(L1)x2
ø2.6x10mm
(K1)x2
ø2.8x10mm
(N1)x4
ø2.6x10mm
(L2)x1
(L3)x1
Rear
Cabinet
CD Mechanism
Top
Cabinet
(M1)x1
ø2.6x8mm
LED PWB
CD Lid Gear
Unit Ass'y
CD Lid
Open/Close
PWB
Figure 13-2
Figure 13-3
(P4)x1
(P5)x1
(P3)x1
ø2x2mm
(P3)x1
ø2x3mm
(P3)x1
ø2x3mm
(P3)x1
ø2x3mm
(P3)x1
ø2x3mm
(P3)x1
ø2x3mm
(P3)x2
ø1.7x3mm
(P1)x2
ø3x6mm
(P1)x2
ø3x6mm
Shield Cover,Top
MD Mechanism
Shield Cover,Side
Shield Cover,Bottom
MD Main PWB
(Note 1)
After removing the flexible PWB for optical pickup from the connector
wrap the front end of flexible PWB in conductive aluminum foil so as
to protect the optical pickup from being damaged electrostatically.
(P2)x1
(P2)x1
(P6)x1
Optical pickup
Flexible PWB (Note 1)
Pull
Pull
