: Error history display menu
: Error history 0 display
ERROR HISTORY DISPLAY
E 0 § §
E 1 § §
E 2 § §
E 3 § §
: Error history display menu
: Error history clear
PLAY
PLAY
E D A T A
E D A T A
C L E A R
E 4 § §
E 5 § §
E 6 § §
E 7 § §
E 8 § §
E 9 § §
• Error history clear
• Error history display
• When the "STOP" button is pressed in specific menu, the TEST MODE STOP state is set.
§ § : Error code
: Error history 1 display
§ § : Error code
: Error history 2 display
§ § : Error code
: Error history 3 display
§ § : Error code
: Error history 4 display
§ § : Error code
: Error history 5 display
§ § : Error code
: Error history 6 display
§ § : Error code
: Error history 7 display
§ § : Error code
: Error history 8 display
§ § : Error code
: Error history 9 display
§ § : Error code
SKIP UP SKIP DOWN
SKIP UP SKIP DOWN
SKIP UP SKIP DOWN
SKIP UP SKIP DOWN
SKIP UP SKIP DOWN
SKIP UP SKIP DOWN
SKIP UP SKIP DOWN
SKIP UP SKIP DOWN
SKIP UP SKIP DOWN
12h: RF side FG, TG, and TCRSG adjustment termination disabled
13h: Excessive servo retract retry in case of adjustment
17h: A, B, E, F, and TCRSO offset measurement time is out of tolerance
21h: Allowable time-over until completion of focus retraction
23h: Track search completion allowable time-over
32h: P-TOC read disabled
42h: U-TOC read disabled
71h: Pickup position initialization time-over
72h: EEPROM data read check sum error
82h: Power overvoltage detection
91h: Ambient temperature exceeds allowable temperature.
: INNER switch position measurement menu
: Continuous playback (pit section)
PLAY
I N N E R
INNER SWITCH POSITION MEASUREMENT
S Q # # # #
• When the "STOP" button is pressed in specific menu, the TEST MODE STOP state is set.
: TEST mode normal playback menu
: Continuous playback mode
PLAY
N O R M A L
TEST MODE NORMAL PLAYBACK
@@@@@@
• When the "STOP" button is pressed in specific menu, the TEST MODE STOP state is set.
@@@@@@ : Mode and address display
