: ATT setting check menu
: Pit section E-ATT (tracking) setting
: Pit section F-ATT (tracking) setting
: Groove section E-ATT (tracking) setting
: Groove section F-ATT (tracking) setting
: High-reflection A-ATT (focus) setting
: High-reflection B-ATT (focus) setting
: Low-reflection A-ATT (focus) setting
: Low-reflection B-ATT (focus) setting
: TCRS-ATT setting
R S L T 2
ATT SETTING CHECK
P E
P F
G E
G F
H A
H B
L A
L B
G C
• When the "STOP" button is pressed in specific menu, the TEST MODE STOP state is set.
• In the specific setting display state the setting change digit changes when the [P-MODE] key is pressed.
P-MODE
P-MODE
P-MODE
• In the specific setting display state the value of selection digit changes in the range of "0
H
to F
H
"
when the [VOL UP/DOWN] key is pressed.
SKIP UP SKIP DOWN
SKIP UP SKIP DOWN
SKIP UP SKIP DOWN
SKIP UP SKIP DOWN
SKIP UP SKIP DOWN
SKIP UP SKIP DOWN
SKIP UP SKIP DOWN
SKIP UP
PLAY
SKIP DOWN
• 3-rd digit setting
1st digit (initial value)
2nd value
3rd digit
: Continuous playback menu
: Continuous playback (pit section)
: Continuous playback (groove section)
: Continuous playback (pit section)
: Continuous playback (groove section)
PLAY
PLAY
DISP
T P L A Y
T P L A Y
CONTINUOUS PLAYBACK
S Q # # # #
A P # # # #
: Continuous playback (pit section)
: Continuous playback (groove section)
: High-reflection pit section B-ATT (focus) setting
: High-reflection groove section B-ATT (focus) setting
PLAY
S Q # # # #
A P # # # #
H B
L B
• When the "STOP" button is pressed in specific menu, the TEST MODE STOP state is set.
• In the start address set state the start address changes as follows when the [DISP] key is pressed.
A d 0 0 5 0
A d 0 0 5 0 A d 0 0 5 0
A d 0 0 5 0
A d 0 3 C 0
DISP DISP DISP
DISP
A d 0 7 0 0
A d 0 8 A 0
• In the start address set state the start address changes as follows when the [BASS] key is pressed.
BASS
BASS
BASS
• In the continuous playback state the number of jump lines changes as follows shown
the [BASS] key is pressed.
1 T R
1 0 T R
BASS
BASS
BASS
4 0 0 T R
• Continuous playback from current pickup position
: Continuous playback menu
: Start address setting
A d 0 0 5 0
S Q # # # #
A P # # # #
• Continuous playback from any address
• In the start address set state the value of selection digit changes in the range of "0
H
to F
H
"
when the [SKIP UP/DOWN" key is pressed.
• In the continuous playback state the state is changed to ATT manual adjustment B-ATT setting
state when the [P-MODE] key is pressed.
• If the [SKIP UP] key is pressed in the continuous playback state, the specified number or lines is
jumped in the external periphery direction.
If the key is held down, the jump continuous with a 100 ms cycle.
• If the [SKIP DOWN] key is pressed in the continuous playback state, the specified number or lines is
jumped in the external periphery direction.
If the key is held down, the jump continuous with a 100 ms cycle.
# # # # : Address
# # # # : Address
# # # # : Address
0 0 5 0
H
(initial value)
0 3 C 0
H
0 7 0 0
H
0 8 A 0
H
1st digit (initial value)
2nd value
3rd digit
: ATT setting
1st line (initial value)
10 lines
400 lines
