: Control setting 7
: Special mode selection data (unprotect area)
: Monitor selection data (unprotect area)
: Control-related other setting data (unprotect area)
Continued from
the preceding page
C T 7
S P M
M S L
R S L
SKIP UP SKIP DOWN
SKIP UP SKIP DOWN
SKIP UP SKIP DOWN
SKIP UP SKIP DOWN
: Setting
: Setting
: Setting
: Setting
• When the "STOP" button is pressed in specific menu, the TEST MODE STOP state is set.
• In specific state pressing the [DISP] key causes change to "focus setting menu".
• In the specific setting display state the setting change digit changes when the [P-MODE] key is pressed.
P-MODE
P-MODE
• In the specific state the setting changes in the range of "0
H
to F
H
" when the
[VOL UP/DOWN] key is pressed.
Note)
In case of EFM output monitoring (eye pattern) with TP201, change "MSL" to 80 from 00.
Before shipment MSL = 00.
1st digit (initial value)
2nd value
To Next Page
