Sharp MD-S301 Service Manual

MD-S301/S301W
– 20 –
: Control setting menu
: Play start SD number, EEPROM version : REC superposition, EL existence/nonexistence, move start minimum  number, high-speed jump over-run : DC-IN existence/nonexistence judgment level, AC adapter judgment level, built-in battery full judgment level : Dubbing mode VOL level setting : Recording bit distribution parameter 1 (invalid)
: Setting of number of empty sectors for servo restart in case of dry cell intermittent operation
: Dry cell exhaustion detection level setting 1 : Dry cell exhaustion detection level setting 2 : Built-in battery exhaustion detection level setting 1 : Built-in battery exhaustion detection level setting 2 : Setting of number of empty sectors for servo restart in case of battery intermittent operation : Control setting 2 : Control setting 3 : Control setting 4 : Control setting 5 : Control setting 6
C T R L
CONTROL SETTING
C T 0
C T 1 P W L
D V L R C 1
D R E
D R 1
D R 2
I N 1
I N 2 I N E
C T 2
C T 3 C T 4 C T 5
C T 6
PLAY
SKIP UP SKIP DOWN
SKIP UP SKIP DOWN
SKIP UP SKIP DOWN
SKIP UP SKIP DOWN
SKIP UP SKIP DOWN
SKIP UP SKIP DOWN
SKIP UP SKIP DOWN
SKIP UP SKIP DOWN SKIP UP SKIP DOWN SKIP UP SKIP DOWN SKIP UP SKIP DOWN
SKIP UP SKIP DOWN
SKIP UP SKIP DOWN
SKIP UP SKIP DOWN
SKIP UP SKIP DOWN
SKIP UP SKIP DOWN
Continued to the next page
: Setting
: Setting
: Setting
: Setting
: Setting
: Setting
: Setting
: Setting : Setting
: Setting
: Setting
: Setting
: Setting
: Setting
: Setting
: Setting
: Digital EQ setting menu
: High-reflection pit section Digital EQ tap factor A, D : High-reflection pit section Digital EQ tap factor B, C : High-reflection pit section Autolevel slicer gain
: High-reflection pit section Autolevel slicer slice level offset : Lows-reflection pit section Digital EQ tap factor A, D : Low-reflection groove section digital EQ tap factor A, D : Lows-reflection pit section Digital EQ tap factor B, C
: Low-reflection pit section Autolevel slicer slice level offset
: Low-reflection pit section Autolevel slicer gain : Low-reflection groove section digital EQ tap factor B, C : Low-reflection groove section Autolevel slicer gain : Low-reflection groove section Autolevel slicer slice level offset : Digital EQ-related other settings
D E Q S E T
DIGITAL EQ SETTING
H Q 1
H Q 2
H S G
H S O
L Q 1 L Q 2
L S G
L S O
G Q 1
G S O
D Q R
G Q 2
G S G
• When the "STOP" button is pressed in specific menu, the TEST MODE STOP state is set. • In specific state pressing the [DISP] key causes change to "focus setting menu". • In the specific setting display state the setting change digit changes when the [P-MODE] key is pressed.
PLAY
SKIP UP SKIP DOWN
SKIP UP SKIP DOWN
SKIP UP SKIP DOWN
SKIP UP SKIP DOWN
SKIP UP SKIP DOWN
SKIP UP SKIP DOWN
SKIP UP SKIP DOWN
SKIP UP SKIP DOWN SKIP UP SKIP DOWN SKIP UP SKIP DOWN SKIP UP SKIP DOWN
SKIP UP SKIP DOWN
: Setting
: Setting
: Setting
: Setting
: Setting
: Setting
: Setting
: Setting : Setting
: Setting
: Setting
: Setting
: Setting
P-MODE
P-MODE
• In the specific state the setting changes in the range of "0
H
to F
H
" when the 
[VOL UP/DOWN] key is pressed.
1st digit (initial value)
2nd value
