PRICE
RANK
DESCRIPTIONNO.
PART CODE NO. PARTS CODE
PRICE
RANK
DESCRIPTION
MD-X5H/CP-X5H
! F805,806 92LFUSET631E J AC Fuse,T630mA L 250V
FE301 RTUNS0007AWZZ J AT FM Front End
FL711 VVK16ST15G/-1 J BH FL Display
FW303 QCNWN1026AWZZ J AE Connector Ass’y,6Pin
FW902 QCNWN1024AWZZ J AF Connector Ass’y,11Pin
FW1901 QCNWN1042AWZZ J AD Flat Cable,5Pin
JK603 QJAKH0001AWZZ J AH Jack,Headphones
JK650 92LJACKL1779A J AG Jack,Analog In/Output
JK651 92LJACKL1776A J AF Jack,Phono
JK652 QJAKZ0009AWZZ J AD Jack,Digital 2 Coaxial
M701 92LMTR1858CASY J AS Motor with Chassis [Spindle]
M702 92LMTR1854BASY J AP Motor with Gear [Sled]
M703 92LMTR1746A J AN Motor with Pulley [Loading]
M800 92LMTR1810A J AK Motor,Air Cooling Fan
M901 RMOTV0012AWZZ J AV MD Spindle Motor Ass’y
M902 RMOTV0013AWM1 J AQ MD Sled Motor Ass’y
M903 RMOTV0014AWM1 J AQ MD Loading Motor Ass’y
RX701 VHL21043TH2-1 J AG Remote Sensor,21043TH2
SO301 QTANC0103AWZZ J AD Antenna Terminal
SO601 QSOCZ0001AWZZ J AN Socket,Key Board
SO801 QTANA0404AWZZ J AF Terminal,Speaker
SW701 92LSWICHL1749A J AD Switch,Leaf Type [Open/Close]
SW702 QSW-F9001AWZZ J AE Switch,Push Type [Pickup In]
SW705 QSW-K0006AWZZ J AC Switch,Key Type [PRE-EQ]
SW706 QSW-K0006AWZZ J AC Switch,Key Type [X-BASS]
SW708 QSW-K0006AWZZ J AC Switch,Key Type [MD-STOP]
SW709 QSW-K0006AWZZ J AC Switch,Key Type
[MD-PLAY/PAUSE]
SW712 QSW-K0006AWZZ J AC Switch,Key Type
[CD-PLAY/PAUSE]
SW713 QSW-K0006AWZZ J AC Switch,Key Type [CD-STOP]
SW717 QSW-K0006AWZZ J AC Switch,Key Type
[CD-OPEN/CLOSE]
SW727 QSW-K0006AWZZ J AC Switch,Key Type [AUX]
SW728 QSW-K0006AWZZ J AC Switch,Key Type
[TUNER (BAND)]
SW729 QSW-K0006AWZZ J AC Switch,Key Type
[TRACK UP/TUNING UP]
SW730 QSW-K0006AWZZ J AC Switch,Key Type
[TRACK DOWN/TUNING
DOWN]
SW731 QSW-K0006AWZZ J AC Switch,Key Type [POWER]
SW732 QSW-K0006AWZZ J AC Switch,Key Type [MD-MD EDIT]
SW733 QSW-K0006AWZZ J AC Switch,Key Type [TRACK]
SW734 QSW-K0006AWZZ J AC Switch,Key Type [CD-MD EDIT]
SW735 QSW-K0006AWZZ J AC Switch,Key Type [MD-REC]
SW736 QSW-K0006AWZZ J AC Switch,Key Type [MD-EJECT]
SW738 QSW-K0006AWZZ J AC Switch,Key Type [VOLUME UP]
SW739 QSW-K0006AWZZ J AC Switch,Key Type
[VOLUME DOWN]
SW901 92LSWICH-1385A J AC Switch,Key Type [RESET]
SW1952 QSW-P0006AWZZ J AG Switch,Push Type [DIRECT]
SW1953 QSW-M0157AFZZ J AD Switch,Slide Type [Lead In]
SW1954 QSW-M0002AWZZ J AD Switch,Push Type [Play]
SW1955 QSW-M0002AWZZ J AD Switch,Push Type [Record]
SW1956 QSW-M0001AWZZ J AD Switch,Push Type [Load]
UNA650 VHPGP1F32R/-1 J AP AUX Digital In Digital 1 Optical,
GP1F32R
MECHANICAL PARTS
1 LANGF0033AWZZ J AD MD Guide (A)
2 LANGF0034AWZZ J AD MD Guide (B)
3 LANGK0092AWFW J AM Base Frame
4 LCHSM0060AWM1 J AP Drive Chassis
5 LHLDX3001AWM1 J AP Holder,Cartridge
6 MLEVF0024AWM1 J AF Lever,Cam Plate
7 MLEVF0025AWZZ J AD Arm,H/A Shift
8 MLEVF0026AWZZ J AF Arm,Holder
9 MLEVF0029AWM1 J AL Lever,Roller Arm
10 MLEVP0075AWZZ J AD Lever,Clampa
11 MLEVP0076AWZZ J AC Catch
12 MLEVP0077AWZZ J AC Lever,Slider
13 MSPRD0103AWFJ J AB Spring,Roller Holder
14 MSPRD0105AWFJ J AB Spring,Spin
15 MSPRD1318AFFJ J AB Spring,Shift Arm
16 MSPRD1319AFFJ J AB Spring,Holder Arm
17 MSPRD1321AFFJ J AB Spring,Lack
18 MSPRD1334AFFJ J AC Spring,Catch
19 MSPRP0015AWFJ J AB Spring,Board (A)
20 MSPRP0017AWFJ J AB Spring,Drive Shaft
21 MSPRT1566AFFJ J AB Spring,Roller
22 NGERH0066AWZZ J AC Gear,Loading (B)
23 NGERH0067AWZZ J AC Gear,Drive
24 NGERH0068AWZZ J AC Gear,Loading (A)
25 NGERH0069AWZZ J AC Gear,Roller
26 NGERR0002AWZZ J AC Gear,Lack
29 NROLP0010AWZZ J AC Holder,Roller
30 NROLR0001AWZZ J AC Roller,Transfer
31 NSFTD0005AWFT J AF Shaft,Drive
32 NSFTM0017AWFW J AC Shaft,Loading Gear
33 NSFTM0277AFFW J AC Shaft,Pickup Slide
34 NSFTM0278AFFW J AC Shaft,Pickup Guide
35 PCOVS3021AWFW J AL Cover,Top
36 PCOVS3022AWFW J AK Cover,Bottom
37 PCUSG0531AFSA J AD Cushion (A)
38 PCUSG0531AFSB J AD Cushion (B)
39 PCUSS0040AWZZ J AC Cushion,Head
40 RCILH0108AFZZ J AP Magnetic Head
41 RCTRH8173AFZZ J BN Optical Pickup Unit
42 QCNWN6715AFM1 J AM MD Flat Cable,24Pin
43 QCNWN6716AFZZ J AL Connector Ass’y,
46 PSHEP0026AWZZ J AC Sheet,H/A Shift Arm
601 LX-BZ0030AWZZ J AB Screw,ø1.7×9.5mm
602 LX-BZ0031AWZZ J AB Screw,ø1.7×7.5mm
603 LX-BZ0032AWZZ J AB Screw,ø1.7×2mm
604 LX-BZ0804AFFF J AA Screw,ø1.4×2.2mm
605 LX-BZ0846AFZZ J AB Screw,ø1.7×3mm
606 LX-BZ0851AFZZ J AB Screw,ø1.7×2.5mm
607 LX-BZ0852AFFD J AC Screw,ø1.7×8.9mm
608 LX-BZ0883AFZZ J AB Screw,ø1.7×5mm
609 LX-WZ9268AFZZ J AA Washer,ø1.5×ø3.2×0.5mm
610 LX-WZ9269AFZZ J AA Washer,ø1.2×ø3×0.25mm
611 XBPSD20P04K00 J AA Screw,ø2×4mm with Washer
612 XSPSN17P03K00 J AB Screw,ø1.7×3mm
M901 RMOTV0012AWZZ J AV MD Spindle Motor Ass’y
M902 RMOTV0013AWM1 J AQ MD Sled Motor Ass’y
M903 RMOTV0014AWM1 J AQ MD Loading Motor Ass’y
SW1952 QSW-P0006AWZZ J AG Switch,Push Type [DIRECT]
SW1953 QSW-M0157AFZZ J AD Switch,Slide Type [Lead In]
SW1954 QSW-M0002AWZZ J AD Switch,Push Type [Play]
SW1955 QSW-M0002AWZZ J AD Switch,Push Type [Record]
SW1956 QSW-M0001AWZZ J AD Switch,Push Type [Loading]
CD MECHANISM PARTS
301 NGERH0011AWZZ J AC Gear,Middle
302 NGERH0012AWZZ J AC Gear,Drive
303 MLEVP0010AWZZ J AC Rail,Guide
304 NSFTM0002AWFW J AE Shaft,Guide
305 PCUSG0427AFSC J AC Cushion
! 306 RCTRH8164AFZZ J BF Pickup Unit Ass’y
306- 1 ———— — Pickup Unit
(Not Replacement Item)
306- 2 NGERR0043AFZZ J AC Gear,Rack
306- 3 MSPRC0961AFZZ J AA Spring,Rack
701 92L2R6S+6CZ J AB Screw,ø2.6×6mm
702 XHBSD20P05000 J AA Screw,ø2×5mm
703 XBBSD20P03000 J AA Screw,ø2×3mm
704 92L1R5WC3R8R25 J AA Washer,ø1.5×ø3.8×0.25mm
M701 92LMTR1858CASY J AS Motor with Chassis [Spindle]
M702 92LMTR1854BASY J AP Motor with Gear [Sled]
SW702 QSW-F9001AWZZ J AE Switch,Push Type [Pickup In]
CABINET PARTS
201 HPNLC1141AWSA J Front Panel
202 GITAR0274AWSA J AQ Rear Panel
203 GCAB-1047AWSA J AQ Top Cabinet
204 GCOVA1154AWSA J AL Cover,CD
205 GITAS0040AWSA J AP Side Panel,Left
206 GITAS0041AWSA J AP Side Panel,Right
207 92LCUSN1746A J AA Cushion,Leg
208 92LN-BAND1318A J AA Nylon Band,80mm
209 LBSHC0002AWZZ J AD Bushing,AC Power Supply Cord
210 LANGK0098AWFW J AH Bracket,PWB
211 LHLDZ1161AWZZ J AK Holder,MD
212 JKNBK0048AWSA J AD Knob,Mic Volume
213 GDORF0037AWSA J AF MD Lid
214 LHLDZ1124AW00 J AC Holder,MD Lid
215 MSPRD0027AWZZ J AB Spring,MD Lid
216 JKNBZ0438AWSA J AH Button,MD Function
218 JKNBZ0417AWSA J AH Button,CD Fanction
219 JKNBZ0418AWSA J AF Button,Volume Up
– 7 –
