MD-X5H/CP-X5H
220 JKNBZ0419AWSA J AF Button,Volume Down
221 JKNBZ0420AWSA J AE Button,X-BASS
222 PSHEP0018AWSA J AH Sheet,FL Display
223 HDECQ0279AWSA J AG Panel,FL Display
224 HDECQ0262AWSA J AF Panel,Volume
225 92LCLMP1810A J AC Wire Holder
226 LHLDZ1001AWZZ J AE Holder,Mechanism
227 GCOVA1001AWSA J AH Disc Holder
228 LHLDM1001AWZZ J AE Stabilizer
229 PMAGF0001AWZZ J AF Magnet
230 NGERR0001AWZZ J AE Gear,Rack
231 92LGEAR1728B J AC Gear,Tray
232 92LPULLY1728A J AB Pulley,Drive
233 92LBELT1728A J AB Belt,Drive
234 LCHSM0001AWZZ J AR Chassis,Loading
235 LANGQ0008AWFW J AE Bracket,Earth
236 LANGK0094AWFW J AH Bracket,Main PWB
237 LCHSM0061AWFW J AQ Main Chassis
238 PSLDM3032AWFW J AF Shield,FL Display (B)
241 NFANP0001AWZZ J AD Rotary Fan
242 92LCSPR1431C J AA Ring Spring,Volume
244 LANGK0107AWFW1J AG Bracket,Fan (A)
245 PRDAR0097AWFW J AG Heat Sink,Main
246 PRDAR0098AWFW J AG Heat Sink,Sub
! 248 92LLUG1746A J AA Terminal,Lug
! 249 92LFSHOLD1652T J AB Holder,Fuse
! 250 QACCB0003AW00 J BA AC Power Supply Cord [For UK]
! 250 QACCE0008AW00 J AG AC Power Supply Cord
[Except for UK]
252 PSLDM3031AWFW J AF Shield,FL Display (A)
253 LHLDZ1086AWZZ J AE Holder,FL Display
254 LANGK0109AWFW J AD Bracket,Key Jack
255 PRDAR0092AWFW J AL Heat Sink (A)
256 PRDAR0105AWFW J Heat Sink (B)
257 PSLDM3042AWFW J Shield,Phono
258 LANGK0108AWFW1J Bracket,Fan (B)
259 PSPAS0003AWZZ J AC Spacer,Fan Support
260 TCAUS0028AWZZ J AB Label,Laser Caution 3B
261 PCUSG0008AWZZ J AB Cushion,Gum
262 NBRGC0003AWZZ J AC Bearing Metal
263 MSPRD0108AWFJ J AC Spring,Fan Motor
264 MSPRB0002AWFW J AC Spring,Key Earth
265 TLABS0140AWZZ J AD Label,Caution [For UK Only]
266 RCORF0002AWZZ J AE Core
267 92LCAUT1706A J AB Label,Laser Caution 3A
268 92LCAUT1706B J AA Label,Laser Caution 3A
269 TSPC-0472AWZZ J AD Label,Specifications
601 XJBSN30P10000 J AA Screw,ø3×10mm
602 XHBSD30P10000 J AA Screw,ø3×10mm
603 XHBSD30P06000 J AA Screw,ø3×6mm
604 LX-JZ0010AFFD J AA Screw,ø3×10mm
605 XJBSF30P08000 J AA Screw,ø3×8mm
606 XBPSD30P10KS0 J AA Screw,
607 LX-HZ0082AFZZ J AA Screw,ø4×8mm
608 XEBSD30P08000 J AA Screw,ø3×8mm
609 LX-WZ7003AWZZ J AB Washer,ø3.2×ø13×1.0mm
610 XEBSD26P10000 J AA Screw,ø2.6×10mm
611 LX-EZ0005AWFD J AA Screw,Special
612 XEBSD26P08000 J AA Screw,ø2.6×8mm
613 XBPSD26P05JS0 J AA Screw,ø2.6×5mm
614 LX-BZ0880AFZZ J AC Screw,ø2×4mm
615 XEBSF30P10000 J AA Screw,ø3×10mm
616 XJBSD30P08000 J AA Screw,ø3×8mm
617 XJBSD30P14000 J AA Screw,ø3×14mm
618 XHSSD30P06000 J AA Screw,ø3×6mm
619 XWHSD32-10130 J AA Washer,ø3.2×ø13×1.0mm
620 XWSSN32-07000 J AB Washer,ø3.2mm
621 XHBSN30P10000 J AA Screw,ø3×10mm
ACCESSORIES/PACKING PARTS
1 SPAKC0576AWZZ J AU Packing Case
2 SPAKA0149AWZZ J AM Packing Add.,Left/Right
3 SSAKH0024AWZZ J AD Polyethylene Bag,Unit
4 92LBAG1460C1 J AB Polyethylene Bag,Accessories
5 QANTL0001AWZZ J AL AM Loop Antenna
6 TINSE0186AWZZ J AP Operation Manual [For UK]
6 TINSZ0271AWZZ J AR Operation Manual
[Except for UK]
7 92LBAG1770A J AB Polyethylene Bag,AC Power
Supply Cord [For UK Only]
8 SPAKP0050AWZZ J AC Polyethylene Bag,Operation
Manual
9 92LF-ANT1535A J AF FM Antenna
10 RRMCG0111AWSA J BB Remote Control
10- 1 GFTAB1020AWSA J Lid,Remote Control
11 TLABE0197AWZZ J AB Bar Cord Label
12 TCAUH0042AWZZ J Caution,Key Board
[Except for UK Only]
13 TCAUZ0032AWZZ J Caution,Phono
[Except for UK Only]
P.W.B. ASSEMBLY (Not Replacement Item)
PWB-A1,2 92LPWB2607TUNS J — Main/Jack
PWB-B1~3 92LPWB2607PWRS J — Power Supply/Display/Power
Amp.
PWB-C 92LPWB2607SYSS J — CD Servo
PWB-D 92LPWB2603MDSS J — MD Main
PWB-E QPWBF0027AWZZ J AD CD Motor (PWB Only)
PWB-F QPWBF0400AWZZ J AC MD Mechanism Switch
(PWB Only)
– 8 –
SPEAKER BOX PARTS
701 92L312-0065 J AQ Front Panel
702 92L121-0108 J AN Net Frame Ass’y,Top
703 92L121-0109 J AN Net Frame Ass’y,Bottom
704 92L051-0047 J AZ Speaker Box Ass’y
705 92L316-0045 J AG Duct Pipe
706 92L291-0057 J AK Speaker Cord
707 93L351-0210 J Label,Specifications
708 92L109-0006 J AH Panel,Decoration,Left
709 92L372-0064 J AB Screw,ø4×16mm
710 92L372-0092 J AB Screw,ø3×8mm
711 92L109-007 J Panel,Decoration,Right
712 92L351-0211 J AE Label,Decoration
C1,2 92L293-0055 J 1.5 µF,50V,Electrolytic,Non-
Polar
SP1,2 VSP0012PBE86A J BA Speaker,Woofer
SP3,4 VSP0050TBH76A J AT Speaker,Tweeter
ACCESSORIES/PACKING PARTS
1 92L412-0089 J AL Packing Add.,Top/Bottom,
Speaker
2 92L411-0089 J AC Polyethylene Bag,Speaker
3 92L414-0017 J AD Sheet
4 TLABM0047AWSA J AK Label,Feature [Except for UK]
4 TLABM0048AWSA J AK Label,Feature [For UK]
