Sharp MX-2310U

MX-3610N MX-SM10 (EXPANSION MEMORY BOARD) 8 – 2
Avoid diagonal insertion of the expansion memory board for
the slot.
Do not push one end of the expansion memory board by one
hand.
Hold the both ends of the expansion memory board with both
hands, and put down the expansion memory so that it is verti-
cal to the PWB.
At that time, check to confirm that the hooks on the left and the
right sides of the slot are securely locked.
C. Shield plate and left cabinet attachment
1) Attach the shield plate.
2) Attach the left cabinet.
D. Turn ON the power of the main unit
1) Connect the power plug of the machine to the power outlet,
and turn ON the main power switch and the operation panel
power switch.
1
2
2
1
2
