TROUBLE CODES
SHARP
50
H5
01
5 continuous (POD1 not reach) jams
H7
10
Fuser low temperature recovery error
(TH_UM_AD2)
11
Fuser low temperature recovery error
(TH_LM)
L1
00
Mirror feed trouble.
L3
00
Mirror return trouble.
L4
02
Paper feed motor lock trouble
03
Fusing motor trouble
04
DV motor trouble K
05
DV motor trouble CMY
06
Transfer unit lift trouble
07
Transfer belt motor trouble
11
Shift motor trouble
12
Secondary transfer separation trouble
16
Fusing pressure release trouble.
31
Paper exit cooling fan trouble
32
Power source cooling fan trouble
34
LSU cooling fan trouble
35
Fusing cooling fan trouble
43
Paper exit cooling fan 3 trouble
50
Process fan trouble
51
Process fan 2 trouble
L6
10
Polygon motor trouble (LSU)
L8
01
No Full wave signal
20
MFP PWB communication trouble
PC
--
Personal counter not installed
U1
01
Battery trouble.
U2
00
MFP EEPROM read/write error
05
HDD internal authentication database
table error.
10
SRAM user authentication index check
sum error
11
MFP PWB EEPROM check sum error.
24
MFP PWB SRAM memory user
authentication counter check sum error
30
Serial number discrepancy (ICU – PCU)
40
SD card error.
41
HDD system storage data area error
42
Machine adjustment data (system
storage area) error
50
HDD user authentication data check sum
error
60
Watermark check error.
80
SCU PWB EEPROM read/write error.
81
SCU PWB EEPROM check sum error.
90
PCU PWB EEPROM read/write error.
91
PCU PWB EEPROM check sum error
U6
00
PCU-Desk communication trouble
01
Tray 1 lift motor trouble
02
Tray 2 lift motor trouble
09
LCC lift motor trouble
10
Desk transport motor trouble
20
LCC communication trouble
21
LCC transport motor trouble
22
LCC 24v power abnormality
50
Desk – Main unit incompatibility trouble
51
LCC – Main unit incompatibility trouble
52
PCU PWB – Paper feed desk
communication trouble.
U7
50
Communication trouble between main
unit and vendor control
51
LCC-Main unit combination trouble
UC
02
CPT-ASIC abnormality
20
Document control module trouble
