Sharp MX-4140N User Guide

Sharp’s belt fusing system
Communication
beyond the firewall
Internet
Power off Off OffPower on On
Start of day
9:00 12:00 13:00 17:00
Lunch break End of day
• Before a print*
1
/copy
command is executed
from the control panel, the
Eco Recommendation*
2
function offers suggestions
on environmentally
friendly settings, helping
users achieve even greater eco-friendly operation.
*1: For printing Document Filing data and direct printing (FTP/SMB/USB).
*2: Contact a Sharp customer representative for details on activating
this function.
• Eco Scan function saves energy by keeping the fusing system
shut down during jobs that don’t require the use of the fusing
system, such as Image Sending and Document Filing.
• Second-generation Mycrostoner-HG has a lower melting point
than conventional toner, allowing fusing to be carried out with
less energy. It also offers a significantly lower consumption rate
than conventional toner.
• For further energy savings, energy-efficient LED lamps are
employed in the scan unit in place
of conventional xenon lamps. A new
ASIC (application-specific integrated
circuit) also helps the MX-5140N/
4140N deliver excellent performance
and energy efficiency.
9
10
Specications for Options
OPTIONS
EXPANDABILITY
Direct Internet Access
The optional Web Browsing Expansion Kit gives you direct
access to the Internet for easy browsing of Web sites on the colour
touchscreen. With such quick access to information, brochures
and user manuals in PDF
format as well as maps
and coupons can be
printed out on the spot.
MX-FX11 Fax Expansion Kit
Compression method MH/MR/MMR/JBIG
Communication protocol Super G3/G3
Modem speed 33,600 bps to 2,400 bps
MX-LC11 Large Capacity Tray
Paper size A4, B5 (8
1
/2" x 11")
Paper capacity 3,500 sheets
Sharp OSA*
(Open Systems Architecture)
Innovative Sharp OSA technology allows you to interact with critical
business and network applications right from the LCD control panel,
offering a new realm of control and convenience. And since Sharp
OSA utilises industry-standard network protocols, the MX-5140N/
4140N can easily integrate with document management systems,
enterprise resource planning software, workflow applications, and
more. The latest version of Sharp OSA can reach beyond the
firewall, enabling extensive system construction and services over
the Internet. Sharp OSA brings benefits such as reducing the costs
associated with system implementation and management, as well as
enabling data sharing across company branch offices or
subsidiaries—effectively enhancing total business efficiency.
* Requires optional MX-AMX2 and/or MX-AMX3.
MX-DE21 Stand with 2,000-Sheet Paper Drawer
Paper size A4 (8
1
/2" x 11")
Paper capacity 2,000 sheets
MX-LT10 Long Paper Feeding Tray
Paper size Max. 1,200 mm long
Paper capacity 1 sheet
ENVIRONMENT-FRIENDLY
• Sharp’s belt fusing system
shortens the MX-5140N/
4140N’s warm-up time to
30/28 seconds, contributing
to reduced overall energy
consumption.
• Based on prior usage patterns, the MX-5140N/4140N
automatically determines the optimal length of time to let elapse
before going into auto power shut-off mode, helping reduce
overall power consumption. Shortly before auto power shut-off
mode begins, a message appears* on the LCD indicating that
the MFP will soon shut down and giving users the option to
continue operation.
* Contact a Sharp customer representative to activate this pop-up
message function.
• Power ON/OFF Schedule function automatically turns the
MX-5140N/4140N on or off according to time schedules set by
the administrator.
Sharpdesk Mobile*
Sharpdesk Mobile is a mobile print/scan application that combines
the convenience of mobile devices and the efficiency of Sharp MFPs
to make conducting business on the go easier than ever. Documents
scanned on a Sharp MFP can be sent to a mobile device to preview
and save. Documents saved on a mobile device can be printed out
on the MFP, sent as e-mail attachments, or used in other
applications.
* Availability varies by country/region. For details, see the Sharpdesk Mobile
support Web site:
http://sharp-world.com/products/copier/docu_solutions/mobile/sharpdesk_mobile/
MX-DE22 Stand with 500-Sheet Paper Drawer
Paper size A3 to A5R (11" x 17" to 5
1
/2" x 8
1
/2"R)
Paper capacity 500 sheets
MX-DE23 Stand with 2 x 500-Sheet Paper Drawer
Paper size (upper and lower tray) A3 to A5R (11" x 17" to 5
1
/2" x 8
1
/2"R)
Paper capacity (upper and lower tray) 500 sheets each
MX-FNX9 Finisher
Paper size Non offset A3W to A5R (12" x 18" to 5
1
/2" x 8
1
/2"R)
Offset/staple A3 to B5 (11" x 17" to 8
1
/
2
" x 11"R)
Max. paper capacity 500 sheets (A4 or smaller),
250 sheets (B4 or larger)
Max. stapling capacity
50 sheets (A4 or smaller), 30 sheets (B4 or larger)
Staple position 3 locations (front, rear or both)
MX-FN11 Finisher
Paper size Non offset A3W to A5R (12" x 18" to 5
1
/2" x 8
1
/2"R)
Offset/staple A3 to B5 (11" x 17" to 8
1
/2" x 11"R)
Max. paper capacity Upper tray 1,550 sheets (A4, 8
1
/2" x 11")
Lower tray 2,450 sheets (A4, 8
1
/2" x 11")
Max. stapling capacity 50 sheets (A4 or smaller),
30 sheets (A4R, B4 or larger)
Staple position 3 locations (front, rear or both)
MX-FN10 Saddle Stitch Finisher
Paper size Non offset A3W to A5R (12" x 18" to 5
1
/
2
" x 8
1
/
2
"R)
Offset/staple A3 to B5R (11" x 17" to 8
1
/2" x 11"R)
Saddle stitch A3, B4, A4R (11" x 17" to 8
1
/2" x 11"R)
Max. paper capacity Offset tray 1,000 sheets (A4 or smaller, except A5R),
500 sheets (A5R, B4 or larger)
Saddle stitch tray 10 sets of 11–15 sheets, 15 sets of 6–10 sheets,
20 sets of 1–5 sheets
Max. stapling capacity
50 sheets (A4 or smaller), 25 sheets (B4 or larger)
Staple position 3 locations (front, rear or both)
MX-FN18 Saddle Stitch Finisher
Paper size Non offset A3W to A5R (12" x 18" to 5
1
/2" x 8
1
/2"R)
Offset/staple A3 to B5 (11" x 17" to 8
1
/2" x 11"R)
Saddle stitch A3W to A4R (12" x 18" to 8
1
/2" x 11"R)
Max. paper capacity Upper tray 1,550 sheets (A4, 8
1
/2" x 11")
Lower tray 2,450 sheets (A4, 8
1
/2" x 11")
Saddle stitch tray 10 sets of 11–15 sheets, 15 sets of 6–10 sheets,
25 sets of 1–5 sheets
Max. stapling capacity
50 sheets (A4 or smaller),
30 sheets (A4R, B4 or larger)
Staple position 3 locations (front, rear or both)
Punch Modules
Model name
Number of holes
Paper weight
For the MX-FNX9 MX-PNX1A MX-PNX1B MX-PNX1C MX-PNX1D
For the MX-FN10 MX-PNX5A MX-PNX5B MX-PNX5C MX-PNX5D
For the MX-FN11/FN18 MX-PNX6A MX-PNX6B MX-PNX6C MX-PNX6D
2 3 4 4 (wide)
55 to 256 g/m
2
*
* Guaranteed punchable weight is 55 to 128 g/m
2
.
System Conguration
MX-PNX5A/B/C/D
Punch Module for MX-FN10
MX-PNX1A/B/C/D
Punch Module for MX-FNX9
MX-PUX1
XPS Expansion Kit
MX-PF10
Barcode Font Kit
AR-SU1
Stamp Unit
MX-EB11
Enhanced Compression Kit
MX-FWX1
Internet Fax Expansion Kit
MX-USX1/X5
Sharpdesk
1/5-License Kit
MX-US10/50/A0
Sharpdesk
10/50/100-License Kit
MX-UN01A/05A
Sharp OSA Network Scanner Tool
1/5-License Kit
MX-UN10A/50A
Sharp OSA Network Scanner Tool
10/50-License Kit
MX-UN1HA
Sharp OSA Network Scanner Tool
100-License Kit
MX-AMX1
Application Integration Module
Certain options may not be available in some areas.
MX-AMX2
Application Communication Module
MX-AMX3
External Account Module
MX-EB12 N
Mirroring Kit
MX-AM10
Web Browsing Expansion Kit
MX-FR42U
Data Security Kit
MX-LT10
Long Paper Feeding Tray
MX-DE21
Stand with
2,000-Sheet
Paper Drawer
MX-KB11 N
Keyboard
MX-FX11
Fax Expansion Kit
MX-LC11
Large Capacity Tray (A4)
MX-RB20
Paper Pass Unit
MX-FNX9
Finisher
MX-DE23
Stand with
2 x 500-Sheet
Paper Drawer
MX-DE22
Stand with
500-Sheet
Paper Drawer
MX-TRX2
Exit Tray Unit
MX-PNX6A/
B/C/D
Punch Module
MX-DS18
Stand
BASE UNIT
Note: When using Sharpdesk, Sharp OSA Network Scanner Tool, and Sharp OSA, please ask your Sharp representative about PC system requirements.
Note: All specifications relating to paper capacity refer to 80 g/m
2
paper.
Outstanding Energy Efficiency
MX-FN10
Saddle Stitch
Finisher
MX-FN11
Finisher
MX-FN18
Saddle Stitch
Finisher
To reduce power consumption, Sharp has applied its advanced technologies across all areas of this MFP, including the hardware, software,
electrical system, and supplies. As a result, the MX-5140N/4140N boasts one of the lowest power consumption rates in its class.
