MX3500N SIMULATION 7 – 54
<Set range and default value of each setup>
* On adjustment values
Each temperature correction value → Temperature 1°C change
by 1 count
Each paper exit count → 1 sheet by 1 count
Each cool-down time → 1s change by 1 count
<Code descriptions of the above list>
43-31
Purpose
Operation check
Function (Purpose)
Used to check the operation of the fusing
web cleaning motor.
Section
Fusing
Item
Operation
Operation/Procedure
1) Remove the fusing unit.
2) Enter the simulation mode with the door open, and press
[EXECUTE] button.
3) Perform the fusing web cleaning motor drive (continuous rota-
tion for 10 sec). After completion, "COMPLETE" is displayed.
Item Display items Item descriptions
Set
range
Default
value
A NN_120_ WUP_HL_UM&HL_E WARMUP end temperature
correction value
120°C or below when turning
on the power under NN
environment
Item Sim. 43-1-A, C 1 to 99 50
B NN_120_WUP_HL_LM Item Sim. 43-1-B 1 to 99 50
C LL_120_ WUP_HL_UM&HL_E 120°C or below when turning
on the power under LL
environment
Item Sim. 43-20-A, C 1 to 99 55
D LL_120_WUP_HL_LM Item Sim. 43-20-B 1 to 99 60
E HH_120_ WUP_HL_UM&HL_E 120°C or below when turning
on the power under HH
environment
Item Sim. 43-21-A, C 1 to 99 50
F HH_120_WUP_HL_LM Item Sim. 43-21-B 1 to 99 50
G ON_120_WUP_HL_UM Temperature correction value
immediately after completion of
warm-up and during continuation
of temperature correction
120°C or below when turning
on the power
Item Sim. 43-1-A 1 to 99 60
H ON 120 WUP HL_E Item Sim. 43-1-C 1 to 99 55
I NN_120_ FUS_DUP_HL_UM & HL_E Fusing temperature correction
value
120°C or below when turning
on the power under NN
environment
Item Sim. 43-4-A, C,
E, G
1 to 99 55
J NN_120_ FUS_DUP_HL_LM Item Sim. 43-4-B, F 1 to 99 50
K LL_120_ FUS_DUP_HL_UM&HL_E 120°C or below when turning
on the power under LL
environment
Item Sim. 43-22-A,
C, E, G
1 to 99 60
L LL_120_ FUS_DUP_HL_LM Item Sim. 43-22-B, F 1 to 99 50
M HH_120_ FUS_DUP_HL_UM&HL_E 120°C or below when turning
on the power under HH
environment
Item Sim. 43-23-A,
C, E, G
1 to 99 50
N HH_120_ FUS_DUP_HL_LM Item Sim. 43-23-B, F 1 to 99 50
O NN_120_ FUS_DUP_CNT Fusing duplex paper exit count Applicable number of sheets for SIM43-24-I, J (NN
environment)
1 to 60 5
P LL_120_ FUS_DUP_CNT Applicable number of sheets for SIM43-24-K, L (LL
environment)
1 to 60 10
Q HH_120_ FUS_DUP_CNT Applicable number of sheets for SIM43-24-M, N (HH
environment)
1 to 60 5
R COOL_DOWN_HEAVY Cool-down time Cool-down time (Heavy paper → Ready) 1 to 60 15
S COOL_DOWN_OHP Cool-down time (OHP → Ready) 1 to 60 30
T COOL_DOWN_DEVELOP Cool-down time (Envelope → Ready) 1 to 60 40
U WUP DUP TIME Temperature correction
continuation time immediately
after completion of warm-up
Applicable time for SIM43-24-G, H (Timer from
completion of ready)
0 to 255 120
V FUS MOTOR Fusing web motor operation
interval
Web motor operation interval 1 to 20 6
TH_UM Fusing upper thermister MAIN center
TH_LM Fusing lower thermister MAIN
TH_E Fusing thermister external
HL_UM Heater lamp upper MAIN
HL_LM Heater lamp lower MAIN
HL_E Heater lamp external
0
A:
A㧦 50
B㧦 50
C㧦 50
D㧦 50
㧧 NN_120_ WUP_HL_UM&HL_E
㧧 NN_120_WUP_HL_LM
㧧 LL_120_ WUP_HL_UM㧒HL_E
㧧 LL_120_WUP_HL_LM
SIMULATION NO.43.-24
FUSER TEMP RESET
50
㨇 1㨪99 㨉
OK
TEST
CLOSE
SIMULATION NO .43-31
TEST
FUSER WEB CLEANIN G CHECK
1/1
0
CLOSE
EXECUTE
To Next Page
