Sharp MX-4501N - Page 161

MX3500N SIMULATION 7 – 53
The highlighted set value is switched and the value is dis-
played in the setting area.
* If there is any item over [↑], an active display is made and
item is shifted.
If there is no item over [↑], the display grays out and the
operation is invalid.
If there is any item under [↓], an active display is made and
item is shifted.
If there is no item over [↓], the display grays out and the
operation is invalid.
3) Enter the set value with 10-key.
* Press [C] key to clear the entered values.
4) When [OK], [↑], [↓] button, [COLOR], or [BLACK] key is
pressed, the currently entered data are saved to EEPROM and
RAM.
* Input value: The intercept for the correction value is 50. This is
because the set value is kept as a positive number in case of a
negative setting due to negative correction.
• Set value: Value to be set (–49 to +49)
Input value: Actual input value (1 to 99)
<List of setting parameters>
* PLAIN BW DUP APP CNT HH, PLAIN CL DUP APP CNT HH,
HEAVY BW DUP APP CNT HH, HEAVY CL DUP APP CNT HH
→ 1s change by 1 count
The other correction values → 1°C change by 1 count
<Code descriptions in the above list>
43-24
Purpose
Setting
Function (Purpose)
Used to enter the correction values for SIM
43-1 and SIM 43-4 temperature correc-
tions.
Section
Fusing
Item
Operation
Operation/Procedure
1) Select the set item with [↑] and [↓] buttons.
The highlighted section of the set value is switched and dis-
played on the set setting area.
* If there is any item over [↑], an active display is made and
item is shifted.
If there is no item over [↑], the display grays out and the
operation is invalid.
If there is any item under [↓], an active display is made and
item is shifted.
If there is no item over [↓], the display grays out and the
operation is invalid.
2) Enter the set value with 10-key.
* Press [C] key to clear the entered values.
3) When [OK], [↑], [↓] button, [COLOR], or [BLACK] key is
pressed, the entered value is set.
* Input value: The intercept for the correction value is 50. This is
because the set value is kept as a positive number in case of a
negative setting due to negative correction.
• Set value: Value to be set (–49 to +49)
Input value: Actual input value (1 to 99)
Set value –49 –25 –5 0 +5 +25 +49
Input value 1 25 45 50 55 75 99
Item Display item Item content
Set
range
Default
value
A HL_UM PLAIN
BW DUP HH
Correction value for TH_UM
BW plain paper duplex
under HH environment
1 to 99 50
B HL_LM PLAIN
BW DUP HH
Correction value for TH_LM
BW plain paper duplex
under HH environment
1 to 99 50
C HL_E PLAIN
BW DUP HH
Correction value for TH_E
BW plain paper duplex
under HH environment
1 to 99 50
DPLAIN BW
DUP APP CNT
HH
Correction value for BW
plain paper duplex
applicable number of sheets
under HH environment
1 to 99 50
E HL_UM PLAIN
CL DUP HH
Correction value for TH_UM
COLOR plain paper duplex
under HH environment
1 to 99 50
F HL_LM PLAIN
CL DUP HH
Correction value for TH_LM
COLOR plain paper duplex
under HH environment
1 to 99 50
G HL_E PLAIN
CL DUP HH
Correction value for TH_E
COLOR plain paper duplex
under HH environment
1 to 99 50
HPLAIN CL
DUP APP CNT
HH
Correction value for COLOR
plain paper duplex
applicable number of sheets
under HH environment
1 to 99 50
I HL_UM
HEAVY BW
DUP HH
Correction value for TH_UM
BW heavy paper duplex
under HH environment
1 to 99 50
J HL_LM
HEAVY BW
DUP HH
Correction value for TH_LM
BW heavy paper duplex
under HH environment
1 to 99 50
K HL_E HEAVY
BW DUP HH
Correction value for TH_E
BW heavy paper duplex
under HH environment
1 to 99 50
L HEAVY BW
DUP APP CNT
HH
Correction value for BW
heavy paper duplex
applicable number of sheets
under HH environment
1 to 99 50
M HL_UM
HEAVY CL
DUP HH
Correction value for TH_UM
COLOR heavy paper duplex
under HH environment
1 to 99 50
N HL_LM
HEAVY CL
DUP HH
Correction value for TH_LM
COLOR heavy paper duplex
under HH environment
1 to 99 50
OHL_E HEAVY
CL DUP HH
Correction value for TH_E
COLOR heavy paper duplex
under HH environment
1 to 99 50
P HEAVY CL
DUP APP CNT
HH
Correction value for COLOR
heavy paper duplex
applicable number of sheets
under HH environment
1 to 99 50
TH_UM Fusing upper thermister main
TH_LM Fusing lower thermister main
TH_E Fusing upper thermister external
HL_UM Heater lamp upper main
HL_LM Heater lamp lower main
HL_E Heater lamp external
Set value –49 –25 –5 0 +5 +25 +49
Input value 1 25 45 50 55 75 99
Item Display item Item content
Set
range
Default
value
0
A:
A㧦 10
㧧 HL_UM PLAI N BW DUP HH
SIMULATION NO.43-23
FUSER TEMP ADJUSTMENT (HH:DUP)
10
㨇 1㨪99㨉㨉
OK
TEST
B㧦 10
㧧 HL_ LM PLAIN BW DUP HH
C㧦 10
㧧 HL_E PL AIN BW DUP HH
D㧦 10
㧧 PLAIN BW DUP APP CNT HH
CLOSE
