MX3500N SIMULATION 7 – 52
43-22
Purpose
Setting
Function (Purpose)
Used to perform L/L (low temperature, low
humidity) correction for the fusing tempera-
ture setting 1 (SIM 43-04) for each paper.
Section
Fusing
Item
Operation
Operation/Procedure
1) When the machine enters Simulation 43-22, the following
screen is displayed. (The current set value is displayed.)
2) Select the set item with [↑] and [↓] buttons.
The highlighted set value is switched and the value is dis-
played in the setting area.
* If there is any item over [↑], an active display is made and
item is shifted.
If there is no item over [↑], the display grays out and the
operation is invalid.
If there is any item under [↓], an active display is made and
item is shifted.
If there is no item over [↓], the display grays out and the
operation is invalid.
3) Enter the set value with 10-key.
* Press [C] key to clear the entered values.
4) When [OK] button is pressed, the currently entered data are
saved to EEPROM and RAM.
* When [↑], [↓], [COLOR], or [BLACK] key is pressed, the current
set value is saved to EEPROM and RAM.
* Input value: The intercept for the correction value is 50. This is
because the set value is kept as a positive number in case of a
negative setting due to negative correction.
• Set value: Value to be set (–49 to +49)
Input value: Actual input value (1 to 99)
<List of setting parameters>
* PLAIN BW DUP APP CNT LL, PLAIN CL DUP APP CNT LL,
HEAVY BW DUP APP CNT LL, HEAVY CL DUP APP CNT LL →
1s change by 1 count
The other correction values → 1°C change by 1 count
<Code descriptions in the above list>
43-23
Purpose
Setting
Function (Purpose)
Used to perform H/H (high temperature,
high humidity) correction for the fusing tem-
perature setting 1 (SIM 43-04) for each
paper.
Section
Fusing
Item
Operation
Operation/Procedure
1) When the machine enters Simulation 43-23, the following
screen is displayed. (The current set value is displayed.)
2) Select the set item with [↑] and [↓] buttons.
Set value –49 –25 –5 0 +5 +25 +49
Input value 1 25 45 50 55 75 99
Item Display item Item content
Set
range
Default
value
AHL_UM
PLAIN BW
DUP LL
Correction value for upper
TH_UM BW plain paper
duplex under LL environment
1 to 99 55
B HL_LM PLAIN
BW DUP LL
Correction value for lower
TH_LM BW plain paper
duplex under LL environment
1 to 99 55
C HL_E PLAIN
BW DUP LL
Correction value for upper
TH_E BW plain paper duplex
under LL environment
1 to 99 55
D PLAIN BW
DUP APP
CNT LL
Correction value for BW
plain paper duplex applicable
number of sheets under LL
environment
1 to 99 50
EHL_UM
PLAIN CL
DUP LL
Correction value for upper
TH_UM COLOR plain paper
duplex under LL environment
1 to 99 55
F HL_LM PLAIN
CL DUP LL
Correction value for lower
TH_LM COLOR plain paper
duplex under LL environment
1 to 99 55
0
A:
A㧦 10
㧧 HL_UM READY HH
SIMULATION NO.43-21
FUSER TEMP ADJUSTMENT (HH)
10
㨇 1㨪99㨉
OK
TEST
B㧦 10
㧧 HL_LM READY HH
C㧦 10
㧧 HL_E  READY HH
D㧦 10
㧧 HL_UM PLAIN BW  HH
CLOSE
G HL_E PLAIN
CL DUP LL
Correction value for upper
TH_E COLOR plain paper
duplex under LL environment
1 to 99 55
H PLAIN CL
DUP APP
CNT LL
Correction value for COLOR
plain paper duplex applicable
number of sheets under LL
environment
1 to 99 50
I HL_UM
HEAVY BW
DUP LL
Correction value for upper
TH_UM BW heavy paper
duplex under LL environment
1 to 99 55
J HL_LM
HEAVY BW
DUP LL
Correction value for lower
TH_LM BW heavy paper
duplex under LL environment
1 to 99 55
K HL_E HEAVY
BW DUP LL
Correction value for upper
TH_E BW heavy paper
duplex under LL environment
1 to 99 55
L HEAVY BW
DUP APP
CNT LL
Correction value for BW
heavy paper duplex
applicable number of sheets
under LL environment
1 to 99 50
M HL_UM
HEAVY CL
DUP LL
Correction value for upper
TH_UM COLOR heavy
paper duplex under LL
environment
1 to 99 55
N HL_LM
HEAVY CL
DUP LL
Correction value for lower
TH_LM COLOR heavy paper
duplex under LL environment
1 to 99 55
O HL_E HEAVY
CL DUP LL
Correction value for upper
TH_E COLOR heavy paper
duplex under LL environment
1 to 99 55
P HEAVY CL
DUP APP
CNT LL
Correction value for COLOR
heavy paper duplex
applicable number of sheets
under LL environment
1 to 99 50
TH_UM Fusing upper thermister main
TH_LM Fusing lower thermister main
TH_E Fusing upper thermister external
HL_UM Heater lamp upper main
HL_LM Heater lamp lower main
HL_E Heater lamp external
Item Display item Item content
Set
range
Default
value
0
A:
A㧦 10
㧧
HL_UM PLAIN BW DUP LL
SIMULATION NO .43-22
FUSER TEMP ADJUSTMENT (LL :DUP)
 10
1 99
OK
TEST
B㧦 50
㧧
HL_LM PLAIN BW DUP LL
C㧦 50
㧧
HL_E PLAIN BW DUP LL
D㧦 50
㧧
PLAIN BW DUP APP CNT LL
CLOSE
