MX3500N SIMULATION 7 – 51
The highlighted section of the set value is switched and dis-
played on the set setting area.
* If there is any item over [↑], an active display is made and
item is shifted.
If there is no item over [↑], the display grays out and the
operation is invalid.
If there is any item under [↓], an active display is made and
item is shifted.
If there is no item over [↓], the display grays out and the
operation is invalid.
3) Enter the set value with 10-key.
* Press [C] key to clear the entered values.
4) When [OK] button is pressed, the currently entered data are
saved to EEPROM and RAM.
* When [↑], [↓], [COLOR], or [BLACK] key is pressed, the current
set value is saved to EEPROM and RAM.
* Input value: The intercept for the correction value is 50. This is
because the set value is kept as a positive number in case of a
negative setting due to negative correction.
• Set value: Value to be set (–49 to +49), Input value: Actual input
(1 to 99)
<List of setting parameters>
*
1
: MX-4500N/4501N only
* WARMUP END TIME HH → 1s change by 1 count
The other correction values → 1°C change by 1 count
<Code descriptions in the above list>
Set value –49 –25 –5 0 +5 +25 +49
Input value 1 25 45 50 55 75 99
Item Item display Content of item
Set
range
Default
value
A HL_UM
READY HH
Correction value for TH_UM
set value in READY
standby under HH
environment
1 to 99 50
B HL_LM READY
HH
Correction value for TH_LM
set value in READY
standby under HH
environment
1 to 99 50
C HL_E READY
HH
Correction value for TH_E
set value in READY
standby under HH
environment
1 to 99 50
D HL_UM PLAIN
BW HH
Correction value for BW
plain paper TH_UM set
value under HH
environment
1 to 99 50
E HL_LM PLAIN
BW HH
Correction value for BW
plain paper TH_LM set
value under HH
environment
1 to 99 50
F HL_E PLAIN
BW HH
Correction value for BW
plain paper TH_E set value
under HH environment
1 to 99 50
G HL_UM PLAIN
CL HH
Correction value for
COLOR plain paper TH_UM
set value under HH
environment
1 to 99 50
H HL_LM PLAIN
CL HH
Correction value for
COLOR plain paper TH_LM
set value under HH
environment
1 to 99 50
I HL_E PLAIN
CL HH
Correction value for
COLOR plain paper TH_E
set value under HH
environment
1 to 99 50
J WARMUP
FUMON
HL_UM T HH
Correction value for fusing
motor front rotation start
TH_UM set value under HH
environment
1 to 99 50
K WARMUP
FUMOFF
HL_LM T HH
Correction value for fusing
motor front rotation end
TH_LM set value under HH
environment
1 to 99 50
L WARMUP END
TIME HH
Correction value for WARM
UP end time under HH
environment
1 to 99 50
M HL_UM HEAVY
HH
Correction value for heavy
paper TH_UM set value
under HH environment
1 to 99 50
N HL_LM HEAVY
HH
Correction value for heavy
paper TH_LM set value
under HH environment
1 to 99 50
OHL_E HEAVY
HH
Correction value for heavy
paper TH_E set value under
HH environment
1 to 99 50
PHL_UM OHP
HH
Correction value for OHP
TH_UM set value under HH
environment
1 to 99 50
Q HL_LM OHP
HH
Correction value for OHP
TH_LM set value under HH
environment
1 to 99 50
R HL_E OHP HH Correction value for OHP
TH_E set value under HH
environment
1 to 99 50
SHL_UM
ENVELOPE
HH
Correction value for
ENVELOPE TH_UM set
value under HH
environment
1 to 99 50
T HL_LM
ENVELOPE
HH
Correction value for
ENVELOPE TH_LM set
value under HH
environment
1 to 99 50
UHL_E
ENVELOPE
HH
Correction value for
ENVELOPE TH_E set value
under HH environment
1 to 99 50
VHL_UM E-
STAR HH
Correction value for
preheating TH_UM set
value under HH
environment
1 to 99 50
WHL_UM PRE-
JOB HH
Correction value for TH_UM
set value when resetting
from preheating under HH
environment
1 to 99 50
X HL_E PRE-
JOB HH
Correction value for TH_E
set value when resetting
from preheating under HH
environment
1 to 99 50
Y HL_UM PLAIN-
45 BW *
1
Correction value for BW
high speed plain paper
TH_UM set value under LL
environment
1 to 99 50
Z HL_LM PLAIN-
45 BW *
1
Correction value for BW
high speed plain paper
TH_LM set value under LL
environment
1 to 99 50
AA HL_E PLAIN-
45 BW *
1
Correction value for BW
high speed plain paper
TH_E set value under LL
environment
1 to 99 50
TH_UM Fusing upper thermister main
TH_LM Fusing lower thermister main
TH_E Fusing upper thermister external
HL_UM Heater lamp upper main
HL_LM Heater lamp lower main
HL_E Heater lamp external
