MX3500N SIMULATION 7 – 50
If there is no item over [↓], the display grays out and the
operation is invalid.
3) Enter the set value with 10-key.
* Press [C] key to clear the entered values.
4) When [OK] button is pressed, the currently entered data are
saved to EEPROM and RAM.
* When [↑], [↓], [COLOR], or [BLACK] key is pressed, the cur-
rent set value is saved to EEPROM and RAM.
* Input value: The intercept for the correction value is 50. This is
because the set value is kept as a positive number in case of a
negative setting due to negative correction.
• Correction value: (–49 to +49) Input value: Actually entered value
(1 to 99)
<List of setting parameters>
*
1
: MX-4500N/4501N only
* WARMUP END TIME LL → 1s change by 1 count
The other correction values → 1°C change by 1 count
<Code descriptions in the above list>
43-21
Purpose
Setting
Function (Purpose)
Used to perform correction of high temper-
ature and high humidity (H/H) environment
for the fusing temperature setting 1 (SIM
43-01) for each paper.
Section
Fusing
Item
Operation
Operation/Procedure
1) When the machine enters SIM 43-21, the following screen is
displayed. (The current set value is displayed.)
2) Select the set item with [↑] and [↓] buttons.
Correction value –49 –25 –5 0 +5 +25 +49
Input value 1 25 45 50 55 75 99
Item Display item Item content
Set
range
Default
value
AHL_UM
READY LL
Correction value for TH_UM
set value in Ready standby
under LL environment
1 to 99 55
B HL_LM
READY LL
Correction value for TH_LM
set value in Ready standby
under LL environment
1 to 99 55
C HL_E READY
LL
Correction value for TH_E
set value in Ready standby
under LL environment
1 to 99 55
D HL_UM PLAIN
BW LL
Correction value for BW
plain paper TH_UM set
value under LL environment
1 to 99 55
E HL_LM PLAIN
BW LL
Correction value for BW
plain paper TH_LM set
value under LL environment
1 to 99 55
F HL_E PLAIN
BW LL
Correction value for BW
plain paper TH_E set value
under LL environment
1 to 99 55
G HL_UM PLAIN
CL LL
Correction value for COLOR
plain paper TH_UM set
value under LL environment
1 to 99 55
H HL_LM PLAIN
CL LL
Correction value for COLOR
plain paper TH_LM set
value under LL environment
1 to 99 55
I HL_E PLAIN
CL LL
Correction value for COLOR
plain paper TH_E set value
under LL environment
1 to 99 55
J WARMUP
FUMON
HL_UM T LL
Correction value for fusing
motor front rotation start
TH_UM set value under LL
environment
1 to 99 60
K WARMUP
FUMOFF
HL_LM T LL
Correction value for fusing
motor front rotation start
TH_LM set value under LL
environment
1 to 99 60
L WARMUP
END TIME LL
Correction value for WARM
UP complete time under LL
environment
1 to 99 80
MHL_UM
HEAVY LL
Correction value for heavy
paper TH_UM set value
under LL environment
1 to 99 60
N HL_LM HEAVY
LL
Correction value for heavy
paper TH_LM set value
under LL environment
1 to 99 60
O HL_E HEAVY
LL
Correction value for heavy
paper TH_E set value under
LL environment
1 to 99 60
PHL_UM OHP
LL
Correction value for OHP
TH_UM set value under LL
environment
1 to 99 60
Q HL_LM OHP
LL
Correction value for OHP
TH_LM set value under LL
environment
1 to 99 60
R HL_E OHP LL Correction value for OHP
TH_E set value under LL
environment
1 to 99 60
S HL_UM
ENVELOPE LL
Correction value for
ENVELOPE TH_UM set
value under LL environment
1 to 99 60
T HL_LM
ENVELOPE LL
Correction value for
ENVELOPE TH_LM set
value under LL environment
1 to 99 60
U HL_E
ENVELOPE LL
Correction value for
ENVELOPE TH_E set value
under LL environment
1 to 99 60
V HL_UM E-
STAR LL
Correction value for
preheating TH_UM set
value under LL environment
1 to 99 60
W HL_UM PRE-
JOB LL
Correction value for TH_UM
set value when resetting
from preheating under LL
environment
1 to 99 60
X HL_E PRE-
JOB LL
Correction value for TH_E
set value when resetting
from preheating under LL
environment
1 to 99 60
Y HL_UM
PLAIN-45 BW
*
1
Correction value for BW
high speed plain paper
TH_UM set value under LL
environment
1 to 99 55
Z HL_LM PLAIN-
45 BW *
1
Correction value for BW
high speed plain paper
TH_LM set value under LL
environment
1 to 99 55
AA HL_E PLAIN-
45 BW *
1
Correction value for BW
high speed plain paper
TH_E set value under LL
environment
1 to 99 55
TH_UM Fusing upper thermister main
TH_LM Fusing lower thermister main
TH_E Fusing upper thermister external
HL_UM Heater lamp upper main
HL_LM Heater lamp lower main
HL_E Heater lamp external
Item Display item Item content
Set
range
Default
value
0
A:
A㧦 60
㧧 HL_UM READY LL
SIMULATION NO.43-20
FUSER TEMP ADJUSTMENT (LL)
60
㨇1㨪99㨉
OK
TEST
B㧦 60
㧧 HL_LM READY LL
C㧦 60
㧧 HL_E READY LL
D㧦 60
㧧 HL_UM PLAIN BW LL
CLOSE
