MX3500N SIMULATION 7 – 49
* When [↑], [↓], [COLOR], or [BLACK] key is pressed, the current
set value is saved to EEPROM and RAM.
<Fusing temperature setting range and default values>
*1
: Japan, China, AB_B
*2
: U.S.A., Canada, Europe, U.K., Australia, Inch, AB-A
43-20
Purpose
Setting
Function (Purpose)
Used to correct the environments of low
temperature and low humidity (L/L) for the
fusing temperature setting 1 for each paper
(SIM 43-01).
Section
Fusing
Item
Operation
Operation/Procedure
1) When the machine enters Simulation 43-20, the screen on the
right is displayed. (The current set value is displayed.)
2) Select the set item with [↑] and [↓] buttons.
The highlighted section of the set value is switched and dis-
played on the set setting area.
* If there is any item over [↑], an active display is made and
item is shifted.
If there is no item over [↑], the display grays out and the
operation is invalid.
If there is any item under [↓], an active display is made and
item is shifted.
Item Display Content
Set
range
Default value
Switch A Switch B Switch C (Cool-down
control YES, default =
OFF)
Thin plain paper Thick plain paper General plain paper
(Cool-down control YES)
MX-3500N/
MX-3501N
MX-4500N/
MX-4501N
MX-3500N/
MX-3501N
MX-4500N/
MX-4501N
MX-3500N/
MX-3501N
MX-4500N/
MX-4501N
Gr. 1
*1
Gr. 2
*2
Gr. 1
*1
Gr. 2
*2
Gr. 1
*1
Gr. 2
*2
Gr. 1
*1
Gr. 2
*2
Gr. 1
*1
Gr. 2
*2
Gr. 1
*1
Gr. 2
*2
A HL_UM PLAIN
PAPER BW DUP
BW plain paper duplex
TH_UM set value
70 to 230 165 165 165 175 170 175 175 180 165 165 170 175
B HL_LM PLAIN
PAPER BW DUP
BW plain paper duplex
TH_LM set value
30 to 200 100 100 100 100 100 100 100 100 100 100 100 100
C HL_E PLAIN
PAPER BW DUP
BW plain paper duplex
TH_E set value
70 to 230 160 160 160 160 160 160 160 160 160 160 160 160
D PLAIN PAPER BW
DUP APP CNT
BW plain paper duplex
applicable number of
sheets
0 to 60000011110000
E HL_UM PLAIN
PAPER CL DUP
COLOR plain paper
duplex TH_UM set value
70 to 230 165 165 165 165 170 175 170 175 165 165 165 165
F HL_LM PLAIN
PAPER CL DUP
COLOR plain paper
duplex TH_LM set value
30 to 200 100 100 100 100 100 100 100 100 100 100 100 100
G HL_E PLAIN
PAPER CL DUP
COLOR plain paper
duplex TH_E set value
70 to 230 160 160 160 160 160 160 160 160 160 160 160 160
H PLAIN PAPER CL
DUP APP CNT
COLOR plain paper
duplex applicable number
of sheets
0 to 60000011110000
I HL_UM HEAVY
PAPER BW DUP
BW heavy paper duplex
TH_UM set value
70 to 230 170 175 170 175 170 175 170 175 170 175 170 175
J HL_LM HEAVY
PAPER BW DUP
BW heavy paper duplex
TH_LM set value
30 to 200 100 100 100 100 100 100 100 100 100 100 100 100
KHL_E HEAVY
PAPER BW DUP
BW heavy paper duplex
TH_E set value
70 to 230 160 160 160 160 160 160 160 160 160 160 160 160
L HEAVY PAPER
BW DUP APP CNT
BW heavy paper duplex
applicable number of
sheets
0 to 60111111111111
M HL_UM HEAVY
PAPER CL DUP
COLOR heavy paper
duplex TH_UM set value
70 to 230 170 175 170 175 170 175 170 175 170 175 170 175
N HL_LM HEAVY
PAPER CL DUP
COLOR heavy paper
duplex TH_LM set value
30 to 200 100 100 100 100 100 100 100 100 100 100 100 100
OHL_E HEAVY
PAPER CL DUP
COLOR heavy paper
duplex TH_E set value
70 to 230 160 160 160 160 160 160 160 160 160 160 160 160
P HEAVY PAPER CL
DUP APP CNT
COLOR heavy paper
duplex applicable number
of sheets
0 to 60111111111111
TH_UM Fusing upper thermister main
TH_LM Fusing lower thermister main
TH_E Fusing upper thermister external
HL_UM Heater lamp upper main
HL_LM Heater lamp lower main
HL_E Heater lamp upper external
0
A:
A㧦175
B㧦100
C㧦160
D㧦 0
㧧 HL_UM PLAIN PAPER BW DUP
㧧 HL_LM PLAIN PAPER BW DUP
㧧 HL_E PLAIN PAPER BW DUP
㧧 PLAIN PAPER BW DUP APP CNT
SIMULATION NO.43㧙04
FUSER TEMP SETUP2 FOR PAPER
175
㨇 70㨪230㨉
OK
TEST
CLOSE
