MX3500N SIMULATION 7 – 48
*1
: Japan, China, AB_B
*2
: U.S.A., Canada, Europe, U.K., Australia, Inch, AB-A
43-4
Purpose
Setting
Function (Purpose)
Used to set the fusing temperature in each
operation mode. (Continued from 43-01.)
Section
Fusing
Item
Operation
Operation/Procedure
1) Select the set item with [↑] and [↓] buttons.
The highlighted set value is switched and the value is dis-
played in the setting area.
* If there is any item over [↑], an active display is made and
item is shifted.
If there is no item over [↑], the display grays out and the
operation is invalid.
If there is any item under [↓], an active display is made and
item is shifted.
If there is no item over [↓], the display grays out and the
operation is invalid.
2) Enter the set value with 10-key.
* Press [C] key to clear the entered values.
3) When [OK] button is pressed, the currently entered data are
saved to EEPROM and RAM.
When setting is completed, [OK] button returns to the normal
display.
J WARMUP FUMON
HL_UM T
Fusing motor front rotation
start TH_UM set value
30 to 200 155 155 155 155 155 155 155 155 155 155 155 155
K WARMUP FUMOFF
HL_LM T
Fusing motor front rotation
end TH_LM set value
30 to 200 30 30 30 30 30 30 30 30 30 30 30 30
L WARM UP END
TIME
WARM UP complete time 30 to 255 235 235 235 235 235 235 235 235 235 235 235 235
MHL_UM HEAVY
PAPER
Heavy paper TH_UM set
value
70 to 230 175 175 175 175 175 175 175 175 175 175 175 175
N HL_LM HEAVY
PAPER
Heavy paper TH_LM set
value
30 to 200 130 130 130 130 130 130 130 130 130 130 130 130
O HL_E HEAVY
PAPER
Heavy paper TH_E set
value
70 to 230 160 160 160 160 160 160 160 160 160 160 160 160
PHL_UM OHP
PAPER
OHP-TH_UM set value 70 to 230 175 175 175 175 175 175 175 175 175 175 175 175
Q HL_LM OHP
PAPER
OHP-TH_LM set value 30 to 200 145 145 145 145 145 145 145 145 145 145 145 145
R HL_E OHP PAPER OHP-TH_E set value 70 to 230 160 160 160 160 160 160 160 160 160 160 160 160
SHL_UM ENV
PAPER
Envelope TH_UM set
value
70 to 230 185 185 185 185 185 185 185 185 185 185 185 185
T HL_LM ENV PAPER Envelope TH_LM set
value
30 to 200 145 145 145 145 145 145 145 145 145 145 145 145
U HL_E ENV PAPER Envelope TH_E set value 70 to 230 170 170 170 170 170 170 170 170 170 170 170 170
V HL_UM E-STAR TH_UM set value when
preheating
30 to 200 150 150 165 165 150 150 165 165 150 150 165 165
W HL_UM PRE-JOB TH_UM set value when
resetting from preheating
30 to 200 165 165 165 165 165 165 175 175 165 165 170 170
X HL_E PRE-JOB TH_E set value when
resetting from preheating
30 to 200 165 165 165 165 165 165 175 175 165 165 170 170
Y HL_UM PLAIN
PAPER BW
BW normal paper
TH1_UM-45
70 to 230 – – 175 175 – – 175 180 – – 175 175
Z HL_LM PLAIN
PAPER BW
BW normal paper TH_LM-
45
30 to 200 – – 130 130 – – 130 130 – – 130 130
AA HL_E PLAIN
PAPER BW
BW normal paper TH_E-
45
70 to 230 – – 160 160 – – 160 160 – – 160 160
Item Display Content
Set
range
Default value
Switch A Switch B Switch C (Cool-down
control YES, default =
OFF)
Thin plain paper Thick plain paper General plain paper
(Cool-down control YES)
MX-3500N/
MX-3501N
MX-4500N/
MX-4501N
MX-3500N/
MX-3501N
MX-4500N/
MX-4501N
MX-3500N/
MX-3501N
MX-4500N/
MX-4501N
Gr. 1
*1
Gr. 2
*2
Gr. 1
*1
Gr. 2
*2
Gr. 1
*1
Gr. 2
*2
Gr. 1
*1
Gr. 2
*2
Gr. 1
*1
Gr. 2
*2
Gr. 1
*1
Gr. 2
*2
TH_UM Fusing upper thermister main
TH_LM Fusing lower thermister main
TH_E Fusing thermister external
HL_UM Heater lamp upper main
HL_LM Heater lamp lower main
HL_E Heater lamp external
0
A:
A㧦170
B㧦130
C㧦155
D㧦175
㧧 HL_UM READY
㧧 HL_LM READY
㧧 HL_E READY
㧧 HL_UM PLAIN PAPER BW
SIMULATION NO.43㧙01
FUSER TEMP SETUP FOR PAPER
170
70 230
OK
TEST
CLOSE
