MX3500N SIMULATION 7 – 75
46-16
Purpose
Adjustment
Function (Purpose)
Used to the copy density adjustment (man-
ual) [Monochrome, all modes] PG print.
Section
Engine
Item
Operation
Operation/Procedure
1) Select the set item with [↑] and [↓] buttons.
The highlighted set value is switched and the value is dis-
played in the setting area.
* If there is any item over [↑], an active display is made and
item is shifted.
If there is no item over [↑], the display grays out and the
operation is invalid.
If there is any item under [↓], an active display is made and
item is shifted.
If there is no item over [↓], the display grays out and the
operation is invalid.
2) Enter the set value with 10-key.
* Press [C] key to clear the entered values.
* The set values can be collectively changed by pressing [ ]
[ ] buttons.
When the set value is not the upper limit value (lower limit
value), the data of each item is increased (decreased) by 1.
3) When [EXECUTE] button is pressed, it is highlighted and self
print is started.
* When [OK], [EXECUTE], [↑], [↓], [ ], [ ] button, [COLOR],
or [BLACK] key is pressed, the data are saved to EEPROM
and RAM.
* After completion of self print, [EXECUTE] button returns to
the normal display.
<Set range and default value of each setup>
46-19
Purpose
Setting
Function (Purpose)
Used to set the BLACK auto exposure
mode.
Section
Scanner
Item
Operation
Operation/Procedure
1) When the machine enters the simulation, the current set status
is highlighted.
2) Press a set value button to be changed, and the button is high-
lighted and the set value is saved to EEPROM and RAM. (In
this example, [MODE2] button is pressed.)
* Only one item can be selected.
* When [CLOSE] button is pressed, the display is shifted to the
copy basic screen of simulation.
* Copying can be performed also by pressing [COLOR]/[BLACK]
key.
<Set range and default value of each set value>
46-21
Purpose
Adjustment
Function (Purpose)
Used to perform the copy color balance
manual correction.
[Color, All modes]: PG print
Section
Engine
Item
Adjustment
Operation/Procedure
1) Select a color with [K][C][M][Y] buttons. The adjustment value
of the selected color is displayed. (In this example, [C] is
selected.)
* Only one color button can be selected. The selected button
is highlighted. (On the default display, [K] is selected.)
* Select the set item with [↑] and [↓] buttons.
The highlighted set value is switched and the value is dis-
played in the setting area.
* If there is any item over [↑], an active display is made and
item is shifted.
If there is no item over [↑], the display grays out and the
operation is invalid.
If there is any item under [↓], an active display is made and
item is shifted.
Item Display Item Set range Default value
A POINT1 Point 1 373 to 627 500
B POINT2 Point 2 373 to 627 500
C POINT3 Point 3 373 to 627 500
D POINT4 Point 4 373 to 627 500
E POINT5 Point 5 373 to 627 500
F POINT6 Point 6 373 to 627 500
G POINT7 Point 7 373 to 627 500
H POINT8 Point 8 373 to 627 500
I POINT9 Point 9 373 to 627 500
J POINT10 Point 10 373 to 627 500
K POINT11 Point 11 373 to 627 500
L POINT12 Point 12 373 to 627 500
M POINT13 Point 13 373 to 627 500
N POINT14 Point 14 373 to 627 500
O POINT15 Point 15 373 to 627 500
To Next Page
