Purpose
Adjustment
Function (Purpose)
Used to execute self-print of the LSU posi-
tion adjustment.
Section
LSU
Item
Adjustment
Operation/Procedure
1) Select the set item with [↑] and [↓] buttons.
The highlighted section of the set value is switched and dis-
played on the set setting area.
* If there is any item over [↑], an active display is made and
item is shifted.
If there is no item over [↑], the display grays out and the
operation is invalid.
If there is any item under [↓], an active display is made and
item is shifted.
If there is no item over [↓], the display grays out and the
operation is invalid.
2) Enter the set value with 10-key.
* When [C] key is pressed, the entered value is cleared.
3) When [EXECUTE] button is pressed, it is highlighted and print-
ing is started.
* After completion of printing, [EXECUTE] button returns to
the normal display.
* When [OK], [↑], [↓] button, [COLOR], or [BLACK] key is
pressed, the value is set to the set item. (The value is not
saved to EEPROM and RAM.)
* When [C], [CA], [SYSTEM SETTINGS], or [EXECUTE] key
is pressed during printing, the operation is interrupted.
* When the machine returns to the ready state after occur-
rence of an interruption, printing is resumed.
<Set range and default value of each set item>
* Item B is displayed as "Display item: Detail of display."
Example: PAPER:CS1
62
62-1
Purpose
Data clear
Function (Purpose)
Used to execute the hard disk format
(except operation manual area).
* Be sure to format the HDD in FAT32.
Section
MFP (HDD)
Item
Clear
Operation/Procedure
1) Press [EXECUTE] button.
[EXECUTE] button is highlighted and [YES] and [NO] buttons
become active.
2) Press [YES] button.
Execute formatting of the hard disk. [YES] button is high-
lighted.
* When [NO] button or [EXECUTE] button is pressed, [EXE-
CUTE] button returns to the normal display, and [YES] and
[NO] buttons gray out.
* When the hard disk formatting is not completed normally,
"HDD FORMAT NG" is displayed.
* After completion of the hard disk formatting, [EXECUTE]
button returns to the normal display, and [YES] and [NO]
buttons gray out.
* When [CA] key is pressed during formatting, the operation is
interrupted and the simulation is terminated. When [SYS-
TEM SETTINGS] key is pressed, formatting is interrupted
and the display returns to the sub number entry screen.
* When [CA] key or [SYSTEM SETTINGS] key is pressed to exit
the simulation, the machine is rebooted.
62-2
Purpose
Operation test/Check
Function (Purpose)
Used to execute the partial check of the
hard disk read/write (except operation man-
ual area).
* Be sure to format the HDD in FAT32.
Section
MFP (HDD)
Item
Operation
Operation/Procedure
1) Press [EXECUTE] button.
[EXECUTE] button is highlighted and [YES] and [NO] buttons
become active.
2) Press [YES] button.
The procedures (Write → Retrieve → Check for any abnormal-
ity.) are executed.
* When [NO] button or [EXECUTE] button is pressed, [EXE-
CUTE] button returns to the normal display, and [YES] and
[NO] buttons gray out.
* When the procedures (Write → Retrieve → Abnormality
check) are not completed normally, "HDD R/W TEST NG" is
displayed.
Item
Display item &
Detail of
display
Description of item Set range
Default
value
A MULTICOUNT Print quantity 1 to 999 1
B PAPER MFT Cassette
select
Manual
feed
1 to 6 1 3 (CS2)
CS1 Cassette 1 2
CS2 Cassette 2 3
CS3 Cassette 3 4
CS4 Cassette 4 5
LCC LCC 6
CLOSE
0
