Sharp MX-5141N

Trouble Codes
46
SHARP
Document Solution Centre
F1
08
Finisher staple shift motor trouble.
10
Finisher staple operation trouble.
11
Finisher grip operation trouble.
15
Finisher exit tray lift operation trouble.
19
Finisher alignment operation trouble F.
20
Finisher alignment operation trouble R
21
Finisher interface fan motor trouble.
22
Finisher rear edge assist motor trouble
23
Finisher shutter trouble
30
Finisher-Saddle communication trouble
31
Saddle Finisher folding sensor trouble.
32
Finisher/Punch unit communication error.
33
Punch unit shift operation trouble.
34
Punch operation trouble.
36
Punch paper edge detection error
37
Finisher data backup RAM error.
38
Punch data backup RAM trouble.
39
Punch paper dust sensor trouble.
41
Saddle paper positioning trouble
42
Saddle guide motor trouble
43
Saddle alignment operation trouble.
44
Saddle staple motor R trouble
45
Saddle staple trouble.
46
Saddle pushing plate motor trouble
47
Saddle paper transport motor trouble.
50
Finisher incompatibility trouble.
51
Saddle sensor connection trouble
52
Finisher micro switch trouble
F2
22
Discharge lamp trouble (K)
23
Discharge lamp trouble (C)
24
Discharge lamp trouble (M)
25
Discharge lamp trouble (Y)
39
Process temperature sensor trouble
40
Toner density sensor trouble (K)
41
Toner density sensor trouble (C)
42
Toner density sensor trouble (M)
43
Toner density sensor trouble (Y)
45
Colour image density sensor trouble
49
LSU thermistor trouble
50
K drum phase sensor trouble
51
Drum phase sensor trouble (Colour)
41cpm
51
Drum phase sensor trouble (Cyan) 51cpm
52
Drum phase sensor trouble (Mag) 51cpm
53
Drum phase sensor trouble (Yel) 51cpm
F2
58
Temperature/humidity sensor trouble
(HUD_M/TH_M)
64
Toner supply operation trouble (K)
65
Toner supply operation trouble (C)
66
Toner supply operation trouble (M)
67
Toner supply operation trouble (Y)
70
Improper toner cartridge detection (K)
71
Improper toner cartridge detection (C)
72
Improper toner cartridge detection (M)
73
Improper toner cartridge detection (Y)
74
Toner cartridge CRUM error (K)
75
Toner cartridge CRUM error (C)
76
Toner cartridge CRUM error (M)
77
Toner cartridge CRUM error (Y)
78
Image density registration sensor trouble
91
High density process control high voltage
error (K)
92
High density process control high voltage
error (C)
93
High density process control high voltage
error (M)
94
High density process control high voltage
error (Y)
F3
12
Paper feed tray 1 lift up trouble
22
Paper feed tray 2 lift up trouble
F6
00
ICU-Fax communication trouble (ICU)
01
Fax EEPROM read/write error.
04
Fax modem operation trouble.
21
LIU & Fax soft switch error (combination)
30
Access error to 1-chip on Fax board.
97
Fax Pwb compatibility trouble.
98
Improper Fax & Destination information.
H2
00
Thermistor open trouble (TH_UM_AD2).
01
Lower thermistor open trouble (TH_LM).
02
Thermistor open trouble (TH_US).
03
Thermistor open trouble (TH_UM_AD1)
H3
00
Fuser high temperature trouble (TH_UM).
01
Fuser high temperature trouble (TH_LM).
