Sharp MX-5141N

Trouble Codes
SHARP
Document Solution Centre
47
H3
02
Sub thermistor fusing section high
temperature (TH_US).
H4
00
Fuser low temperature (TH_UM_AD2)
01
Fuser low temperature (TH_LM)
02
Sub thermistor fusing section low
temperature (TH_US)
30
Thermistor input circuit trouble (TH_UM)
H5
01
5 continuous (POD1 not reach) jams
H7
10
Fuser low temperature recovery error
(TH_UM_AD2)
11
Fuser low temperature recovery error
(TH_LM)
L1
00
Scanner feed trouble.
L3
00
Scanner return trouble.
L4
02
Paper feed motor trouble
03
Fusing motor trouble
04
DV motor trouble K
05
DV motor trouble CMY
06
Transfer unit lift trouble
07
Transfer belt motor trouble
11
Shift motor trouble
16
Fusing pressure release trouble
30
Controller fan motor
31
Paper exit cooling fan trouble
32
Power source cooling fan 1 trouble
34
LSU cooling fan trouble
35
Fusing cooling fan trouble
45
Toner cooling fan trouble (Toner cooling
fan 1 or 2)
50
Process fan trouble
56
Rear cooling fan trouble
58
Ozone exhaust fan trouble
L6
10
Polygon motor trouble (LSU)
L8
01
No Full wave signal
02
Full wave signal error
20
MFP PWB/LSU mother board
communication trouble
PC
--
Personal counter not installed
U1
01
Battery trouble.
U2
00
MFP EEPROM read/write error
05
Erroneous detection of account
management data
11
MFP PWB EEPROM check sum error.
30
Serial number discrepancy (MFP – PCU)
40
SD card system storage data error
41
HDD system storage data area error
42
Machine adjustment data (system storage
area) error
50
HDD user authentication data sum error
60
Watermark check error.
80
SCU PWB EEPROM read/write error.
81
SCU PWB EEPROM check sum error.
90
PCU PWB EEPROM read/write error.
91
PCU PWB EEPROM check sum error
U5
00
Document feeder unit communication
trouble
16
Document feeder unit fan trouble
30
Document feeder tray lift up trouble
31
Document feeder tray lift down trouble
U6
00
PCU-Desk communication trouble
01
Desk Unit Tray 1 lift motor trouble
02
Desk Unit Tray 2 lift motor trouble
09
LCC lift motor trouble
10
Desk transport motor trouble
