Sharp MX-C250

MX-C250 SIMULATION 6 – 72
27 1, 2 Timer T5 timer setting 1min 0 0 Two states input
5min 0 1
10min 1 0
15min 1 1
3 Setting Sharp machine mode 0 : OFF 1 : ON
4 Setting V.34 mode function 0 : OFF 1 : ON
5 Setting V.34 mode function at times of
manual communication
0 : OFF 1 : ON
6 - 7 Communication/
Setting
Coding capacity during transmis-
sion and reception (V.34 communi-
cation) (reflected in DIS/DCS/
DTC)
JBIG/MMR/MR/MH 0 0
MMR/MR/MH 0 1
MR/MH 1 0
MH 1 1
8 Not used
28 1, 2 Communication/
Setting
Coding capacity during transmis-
sion and reception (other than V.34
communication) (reflected in DIS/
DCS/DTC)
JBIG/MMR/MR/MH 0 0 Two states input
MMR/MR/MH 0 1
MR/MH 1 0
MH 1 1
3, 4 Setting 300bps preamble send out time 1.0s 0 0
1.0s 0 1
1.5s 1 0
2.0s 1 1
5 Setting Error handling when transmission
and receiving RTN
0 : Error 1 : Not error
6 Setting PIN code correspondence 0 : OFF 1 : ON
7 - 8 Not used
29-
30
Not used
31 1 - 3 Setting Symbol rate transmission Automatic 0 0 0
2400 0 0 1
2400/2743 0 1 0
2400/2743/2800 0 1 1
2400/2743/2800/3000 1 0 0
2400/2743/2800/3000/3200 1 0 1
2400/2743/2800/3000/3200/
3429
1 1 0
Not used 1 1 1
4 - 7 Communication/
Setting
Modem transmission speed (less
than V.33 mode)
V.27 2400bps 0 0 0 0
v.29 9600bps 0 0 0 1
V.27 4800bps 0 0 1 0
V.29 7200bps 0 0 1 1
V.33 14.4kbps 0 1 0 0
V.33 12.0kbps 0 1 1 0
V.17 9600bps 1 0 0 1
V.17 12.0kbps 1 0 1 0
V.17 7200bps 1 0 1 1
V.17 14.4kbps Other setting values than
above settings
8 Communication/
Setting
Echo countermeasure (setting of
hold time between DIS reception
and sending of signal) when trans-
mitting.
0 : 500ms 1 : 800ms
32 1, 2 Communication/
Setting
Echo countermeasure (setting of
hold time between DIS reception
and sending of signal) when trans-
mitting.
0 : Once when performing
NSF reception
Twice when performing DIS
reception
0 0 Two states input
Twice regardless of NSF
reception
0 1
Once regardless of NSF
reception
1 0
Not used 1 1
3 Setting Echo suppressor tone setting 0 : OFF 1 : ON
4 Setting Training 0 : Short training 1 : Long training
5, 6 Phase-C head dummy data send
time
0.2s 0 0
0.3s 0 1
0.4s 1 0
0.5s 1 1
7, 8 Not used
SW
No.
Bit
No.
System set-
tings
Item SW selection and function Remarks
