MX-C250 SIMULATION 6 – 66
3) Determine the setting values with [OK]/[START] key.
4) Press [OK]/[START] key to send the sound messages.
<Sound message table>
66-10
Purpose
Data clear
Function (Purpose)
Used to clear the FAX image data.
Section
FAX
Operation/Procedure
1) Press [OK]/[START] key.
2) After completion of clearing, press [CA] key to reboot the
machine.
66-11
Purpose
Operation test/Check
Function (Purpose)
Used to send the selected signal at 300bps
to the line and the speaker.
Section
FAX
Operation/Procedure
1) Select an item to be set with 10 keys.
2) Determine the setting values with [OK]/[START] key.
3) Press [OK]/[START] key and a selected signal is sent .
<300bps send signal table>
66-13
Purpose
Setting
Function (Purpose)
Used to execute the dial send test.
Section
FAX
Operation/Procedure
The dials which can be sent are as follows
- Dial pulse 10PPS
- Dial pulse 20PPS
- DTMF
1) Select an item to be set with 10 keys.
2) Determine the setting values with [OK]/[START] key.
3) Press [OK]/[START] key and a selected dial is sent .
66-17
Purpose
Operation test/Check
Function (Purpose)
Used to send the DTMF signal to the line
and the speaker.
Section
FAX
Operation/Procedure
1) Select an item to be set with 10 keys.
2) Determine the setting values with [OK]/[START] key.
3) Press [OK]/[START] key and a selected dial is sent.
66-21
Purpose
Check
Function (Purpose)
Used to print the selected items (FAX set-
ting list, software SW list, protocol monitor).
Section
FAX
Operation/Procedure
1) Select an item to be set with 10 keys.
2) Determine the setting values with [OK]/[START] key.
3) Press [OK]/[START] key and printing is started.
66-30
Purpose
Operation test/Check
Function (Purpose)
Used to display the TEL/LIU status change,
The display is highlighted by status change.
Section
FAX
Operation/Procedure
1) Press [OK]/[START] key and check the condition after the status
is changed.
<TEL/LIU status change item description>
66-31
Purpose
Setting
Function (Purpose)
Used to set ON/OFF the port for output to
TEL/LIU.
Section
FAX
Operation/Procedure
1) Select an item to be set with 10 keys.
2) Determine the setting values with [OK]/[START] key.
3) Press [OK]/[START] key and the changed setting is reflected to
the port which outputs to TEL/LIU.
<Port which outputs to TEL/LIU>
No. Sound message
1NONE
2 FAX/TEL MSG
3 FAX/TEL MSG
4 FAX/TEL MSG
5RINGER
6 EXT.TELRINGER
No Signal No Signal
1 No signal (CML ON) 4 00000
2 11111 5 010101
3 11110 6 00001
Signal Notice (Signal Low) Notice (Signal High)
EXRHS Inversion No inversion
1: CION 2 : 150VON 3 : EC
