MX-C250 MX-C250/MX-C250E/MX-C250F/MX-C250FE/MX-C300E/MX-C300F/C300W/C300WE(MAIN UNIT) 2 – 3
C. Fusing unit lever
1) Open the right door unit..
2) Turn the levers of the Fusing unit to add the pressure.
NOTE: When the machine is left for one month without using, the
Fusing heat roller could be deformed. If the machine is not
going to be used for an extended period, release the pres-
sure on the fusing rollers.
4. Tray size setup
1) Gently pull out the tray until it stops. If paper is in the tray,
remove it.
2) Adjust the guide plates A and B to the vertical size and the hori-
zontal size of paper.
The guide plates A and B are movable. Hold the fixing knob to
slide the guide plates A and B to match the paper size.
3) Insert the tray slowly.
4) Turn ON the machine and press the [SPECIAL FUNCTION]
key on the LCD, and press the [UP] or [DOWN] key to select
"Paper Size Set".
5. Line cable connection (Only for the machine
with FAX)
1) Connect the line cable on the line to the modular jack indicated
as “LINE.”
It is necessary to prepare the line cable by yourself. The line cable
is not installed into the machine.
When connecting the line cable (to LINE or TEL), wind the line
cable two turns or one turn around the included ferrite core as
shown in the figure, and connect to the modular jack which is
marked with “LINE.”
To Next Page
