35
REPLACING SUPPLIES AND MAINTENANCE
6
Repeat step 5 with each of the other main chargers.
There are a total of 4 places to be cleaned in the machine as shown.
7
Replace the charger cleaner in its original position.
Insert the tip of the charger cleaner in toward the right and then press down on
the end of the charger cleaner. The charger cleaner will lock into place.
8
Close the main charger cover and rotate the lock
levers in the direction of the arrows to lock the cover.
☞ Replacing the developer cartridge (page 18)
Main charger
(1)
(2)
mxc401_us_saf.book 35 ページ ２００８年１０月１５日 水曜日 午前１１時５２分
