20
REPLACING SUPPLIES AND MAINTENANCE
4
Remove the developer cartridge.
(1) Grasp the developer cartridge lock and pull it forward
and down.
(2) Squeeze the lever on the developer cartridge
(3) Pull the developer cartridge out horizontally.
(4)
Support the developer cartridge near the middle with your
hand and completely remove the developer cartridge.
• When removing the developer cartridge, grasp it with both hands at
the middle.
• Try to keep the developer cartridge horizontal as you remove it. If
tipped during removal, developer may spill out.
• There will be toner on the roller area of the removed developer
cartridge. Do not touch the roller area. If you accidentally touch the
toner, immediately wash your hands.
(2) (2)
(3)
Roller
mxc401_us_saf.book 20 ページ ２００８年１０月１５日 水曜日 午前１１時５２分
To Next Page
