5028
Tray 1 sensor (media out) cable is unplugged service check
Upper paper path sensors service check
Diagnostics and troubleshooting
192
Action
Yes
No
Step 1
Check the following sensors for proper connection, and reseat if
necessary:
• Sensor (output)
• Sensor (bin full)
Does the problem remain?
Go to step 2.
The problem is
solved.
Step 2
Check the sensor cables for proper connection on the sensors and
on the JDSNS1 connector on the controller board.
Are the cables properly connected at both ends?
Go to step 4.
Go to step 3.
Step 3
Reconnect the cables.
Does the problem remain?
Go to step 4.
The problem is
solved.
Step 4
Check the sensors for damage, and replace if necessary.
Does the problem remain?
Contact the next
level of support.
The problem is
solved.
Action
Yes
No
Step 1
Check the cable on the JMTR1 connector on the controller board
for proper connection, and reseat if necessary.
Does the problem remain?
Go to step 2.
The problem is
solved.
Step 2
a Remove the media feeder. See “Media feeder removal” on
page 411 .
b Check the cable on the sensor (media out), and reseat if
necessary.
Does the problem remain?
Go to step 3.
The problem is
solved.
Step 3
Replace the media feeder. See “Media feeder removal” on
page 411 .
Does the problem remain?
Contact the next
level of support.
The problem is
solved.
