MX-M182 SIMULATIONS 7-22
26 20 Job separator paper exit mode setting
Used to set the paper exit mode of the job separator.
* The purpose is to allow the simplified check when the job separator option is installed. It is valid only
during the adjustment simulation. Without installing a printer or a FAX machine, paper is discharged to
the upper stage to check if there is no problem or not.
If SIM26-01 is set to "Job separator not installed," paper is discharged to the lower stage regardless of
this setting.
[CA] key: Exits the simulation mode.
[INTERRUPT] key: Shifts to the sub code input window.
Default:
0
22 Language setting clear
Used to clear the language setting. The scanner head is shifted to the fixing lock position.
30 CE mark conformity control ON/OFF
Used to set Yes/No of CE mark conformity.
When this simulation is executed, the current set value is displayed. Enter a value with numeric keys and
press [OK] key or [START] key. The set value is saved to EEPROM and the machine returns to the sub code
input window.
[CA] key: Exits the simulation mode.
[INTERRUPT] key: Shifts to the sub code input window.
Default:
0: 100V series
1: 200V series
Main
code
Sub
code
Contents Remark
Sim26-20 JOBSEP OUT
1:JOBSEP OUT
0=OFF 1=ON
[ 0-1]
Code: Setting
0: Lower tray
1: Upper tray
0
0
Sim26-22 LANGUAGE
AER YOU SURE? EXEC
LANGUAGE SETTING
CLEAR
[OK] key or [START] Key
(Execution is started)
After completion of counter clear
and shifting to the lock position.
(Intial display)
Sim26-22 LANGUAGE
LANGUAGE SETTING
CLEAR
EXEC
Sim26-22 LANGUAGE
PLEASE SHUT OFF
THE POWER.
Sim26-30 CE MARK
1:CE MARK CTRL
0=OFF 1=ON
[ 0-1]
Code: Setting
0 : CE mark support control OFF
1 : CE mark support control ON
0
0
