MX-M200D SIMULATIONS 7-13
16 - U2 trouble cancel
* Used to cancel the U2 trouble and execute the hard reset.
When this simulation is executed, the following execution start window is displayed. Press [OK] key or
[START] key to clear the U2 trouble.
20 01 Maintenance counter clear
Used to clear the maintenance counter.
Press [OK] key or [START] key on the following window, the maintenance counter is cleared and the
machine returns to the sub code input window.
21 01 Maintenance cycle setting
Used to set the maintenance cycle. When this simulation is executed, the current set value is displayed.
Enter a desired code with numeric keys and press [START] key. The set value is saved in the EEPROM and
the machine returns to the sub code input window.
[CA] key: Exits the simulation mode.
[INTERRUPT] key: Returns to the sub code input window.
Default:
4
22 01 Counters display
Though SIM26-74 is set to “1: Scan counter is added,” the count is not added to SIM22-01 total counter
display. The setting affects only the total counter display in the system settings.
Main
code
Sub
code
Contents Remark
Sim16 TROUBLE CLEAR
AER YOU SURE? EXEC
U2 TROUBLE CLEAR
(Execution start window)
Sim20-1 COUNTER CLR
AER YOU SURE? EXEC
MAINTENANCE COUNTER
CLEAR
Sim21-1 CYCLE SET.
4
4[ 0- 5]
1:MAINTE CYCLE
0: 5K (5,000 sheets)
1: 7.5K (7,500 sheets)
2: 10K (10,000 sheets)
3: 25K (25,000 sheets)
4: 50K (50,000 sheets)
5: FREE (999,999 sheets)
(Setting range: 0 - 5)
Sim22-1 COUNTER 1/4
TOTAL :nnnnnnn
MAINTE :nnnnnnn
DEV :nnnnnnn(*)
MIN_MNT :nnnnnnn(*)
DRUM :nnnnnnn
Sim22-1 COUNTER 2/4
key key
CPY JOB : nnnnnnn
PRT JOB : nnnnnnn
SCN JOB : nnnnnnn
OC SCN : nnnnnnn
Sim22-1 COUNTER 3/4
SPF : nnnnnnn
DUPLEX : nnnnnnn
OTHERS : nnnnnnn
MNTCYC : nnnnnnn
Sim22-1 COUNTER 4/4
DRM TTL : nnnnnnn
MMTCYC : nnnnnnn
Counter display
TOTAL : Total counter
MAINTE : Maintenance counter
DEV : Development counter
DRUM : Drum counter
CPY JOB : Copy job counter
PRT JOB : Print job counter
SCN JOB : Scan job counter
OC SCN : OC scan counter
SPF : SPF/RSPF counter
DUPLEX : DUPLEX counter
OTHERS : Other counter
MNTCYC : Maintenance cycle
DRM TTL :Drum rotation accumulated time
key key
key key
