MX-M200D SIMULATIONS 7-15
22 13 CRUM destination display
Used to display the CRUM chip destination code saved in the EEPROM. If the display does not match the
destination code saved in the CRUM chip, it is judged as an error.
* This simulation is valid only for the model with the CRUM chip.
14 P-ROM version display
The version of the option board which is not installed is not displayed.
15 Trouble memory display
The latest 20 troubles are displayed. (The oldest one is overwritten sequentially.)
[CA] key: Exits the simulation mode.
[INTERRUPT] key: Shifts to the sub code input window.
key, key: Switches to another page.
The display sequence is as shown below.
In this case, (1) is the latest one and (12) is the oldest.
22 SPF/RSPF jam counter display
Used to display the SPF/RSPF JAM counter.
When [INTERRUPT] key is pressed, the machine goes to the sub code input window. When [CA] key is
pressed, the machine exits the simulation mode.
(Only when the
SPF/RSPF is
installed.)
24 01 Jam total counter clear
When this simulation is executed, the clear confirmation window is displayed as shown below.
When [OK] key or [START] key is pressed, the jam total count and the jam memory are cleared and the
machine shifts to the sub code input window.
Main
code
Sub
code
Contents Remark
Sim22-13 CRUM
CRUM TYPE nn
Number : Setting (Destination)
00 : Not set.
04 : CHN-A
05 : JPN-A
07 : BTA-A
08 : BTA-B
09 : BTA-C
99 : Conversion
Sim22-14 ROM VER1/2
S/N : -----------
MCU : --.--
IMC : --.--
PNL : --.--
Sim22-14 ROM VER2/2
FAX : --.--
S/N :Production serial number
MCU :Main unit program version
IMC :IMC program version
PNL :Panel program version
FAX :FAX program version
Sim22-15 TROUBLE 1/2 Sim22-15 TROUBLE 2/2
XX-XX XX-XX XX-XX
XX-XX XX-XX XX-XX
XX-XX XX-XX XX-XX
XX-XX XX-XX XX-XX
XX-XX XX-XX XX-XX
XX-XX XX-XX XX-XX
XX-XX XX-XX
key
key
Sim22-15 TROUBLE 1/2
1
2
3
4
5
6
7
8
9
10
11
12
Sim22-22 JAM CNT
SPF : nnnnnnn
Sim24-1 COUNTER CLR
AER YOU SURE? EXEC
JAM COUNTER CLEAR
