MX-M200D SIMULATIONS 7-29
44 16 Toner density control data check and toner density correction quantity display
The output value of the ATC sensor is checked, and the toner density control correction quantity is displayed
on the LCD.
[CA] key: Exits the simulation mode.
[INTERRUPT] key: Shifts to the sub code input window.
34 Transfer current setting
Used to set the transfer current value. When this simulation is executed, the list of modes and the current set
value are displayed on the LCD.
Select a set item with the arrow keys and enter a set value with numeric keys. Press [OK] key or [START]
key, and the set value is saved in the EEPROM.
The setting range is 90µA - 360µA. The calculation formula is "Set value x 10 (µA)."
For example, in order to set the transfer current value to 200µA, set the adjustment value to "20."
* Small size paper means A4R (Letter R) width or less.
* When selecting the special size of tray, the normal size width setting is made.
Default:
NML F: 22
NML R: 21
SML F: 22
SML R: 21
BYPASS: 22
46 01 Copy density adjustment(300dpi)
Used to set the copy density foe each exposure mode.
When this simulation is executed, the list of the setting items and the current set value are displayed.
Select an item to be changed with [ ] key and [ ] key and enter the adjustment value with numeric keys.
The setting range is 1 - 99.
When [ ] key or [ ] key is pressed, the page is changed.
Enter the adjustment value with numeric keys and press [OK] key. The entered value is saved in the
EEPROM and the machine shifts to the copy window.
Sample copying can be performed during the simulation
Main
code
Sub
code
Contents Remark
Name
TONER DEN_LT
TONER DEN_ST
:Display content
:Current ATC sensor value
:ATC reference value with life correction
quantity added
Sim44-16 TONER DISP
1:TONER DEN_LT
nnn
2:TONER DEN_ST
nnn
Sim44-34 TC ADJ.
1:NML F
2:NML R
3:SML F
1/2 [ 9- 36]
22
21
22
22
Sim44-34 TC ADJ.
4:SML R
5:BYPASS
2/2 [ 9- 36]
21
22
22
Display mode : Setting mode
NML F : Normal size paper (Front)
NML R : Normal size paper (Back)
SML F : Small size paper (Front)
SML R : Small size paper (Back)
BYPASS : Manual paper pass
Sim46-1 EXP LEVEL
1:AE
2:TEXT
3:PHOTO 1
1/2 [ 1- 99]
50
50
50
50
Sim46-1 EXP LEVEL
4:PHOTO 2
5:TEXT(TS)
6:AE(TS)
2/2 [ 1- 99]
50
50
50
50
Window display : Adjustment mode
1:AE : AE MODE (300dpi)
2:TEXT : TEXT MODE (300dpi)
3:PHOTO 1 : PHOTO MODE (Error diffusion)
4:PHOTO 2 : PHOTO MODE (Dither)
5:TEXT (TS) : TS MODE (TEXT) (300dpi)
6:AE (TS) : TS MODE (AE) (300dpi)
To Next Page
