Sharp MX-M453N Installation Manual

MX-M503N CONFIGURATION - i
: '10/Jun/18
1
MX-M503N
Service Manual CONFIGURATION
1. Main unit and option
1
Paper exit system
Paper feed system
MX-SCX1
12
10
FINISHER
MX-FNX9
7
STAND/2 x 500 SHEET
PAPER DRAWER
MX-DEX9
4
PUNCH MODULE
STAPLE CARTRIDGE
MX-SCX1
12
STAPLE CARTRIDGE
STAPLE CA
(For saddle)
RTRIDGE
MX-PNX1
A/B/C/D
AR-SC3
13
PUNCH MODULE
MX-PNX5
A/B/C/D
11
SADDLE STITCH FINISHER
MX-FN10
9
PAPER PASS UNIT
MX-RBX3
8
PAPER PASS UNIT
MX-RBX3
8
EXIT TRAY UNIT
MX-TRX2
6
STAND/1 x 500 SHEET
PAPER DRAWER
MX-DEX8
3
STAPLE CARTRIDGE
AR-SC2
16
PUNCH MODULE
MX-PNX6
A/B/C/D
15
FINISHER
MX-FN11
14
DIGITAL MULTIFUNCTIONAL SYSTEM
MX-M363U/M453U/M503U
DIGITAL MULTIFUNCTIONAL SYSTEM
MX-M283N/M363N/M453N/M503N
DIGITAL MULTIFUNCTIONAL SYSTEM
MX-M282N/M362N/M452N/M502N
LARGE CAPACITY TRAY
MX-LCX1
5
Document reading system
DOCUMENT COVER
MX-VRX1
1
REVERSING SINGLE
PASS FEEDER
MX-RP11
2
Other
PLASMACLUSTER ION
GENERATOR
MX-PC11
43
PLASMACLUSTER ION
GENERATOR
MOUNTING KIT
MX-XB13
44

Sharp MX-M453N Specifications

General

Functions	Copy, Print, Scan
Print Speed	45 ppm
Print Resolution	1200 x 1200 dpi
Duplex Printing	Yes
Hard Disk Drive	80 GB
Scan Resolution	600 x 600 dpi
Maximum Copy Paper Size	A3
Warm-up Time	20 seconds
Paper Capacity	Standard: 1, 100 sheets, Maximum: 5, 600 sheets
Network Connectivity	Ethernet
Memory	Standard: 1 GB
Copy Speed	45 ppm
Copy Paper Capacity	Standard: 1, 100 sheets; Maximum: 5, 600 sheets
Power Consumption	1.84 kW
