MX-M753N MX-CF10 4 – 4
2) Attach the positioning pin with two fixing screws I to the left
upper section of the main unit. Be careful to the attachment
direction of the positioning pin.
NOTE: For fixing screws H and I, use the packaged parts of the
MX-FN14/FN15/FN16.
3) Attach the earth plate with the fixing screws H (2 pcs.) to the
left lower section of the main unit.
In this case, attach so that the R mark on the earth plate faces
up.
4) Pull out the lock release lever on the left side of the main unit,
and open the left door.
5) Remove the paper exit cover on the upper side of the left door.
6) Close the left door.
7) Attach the connecting plate to the with fixing screws I (2 pcs.)
main unit.
D. Install the positioning plate and the button
cover to the finisher
1) Remove the step screw (1 pc) and the screws (2 pcs.) which
are fixing the punch cover.
2) Attach the interlock pin (1 pc.) to the mounting plate with a
screw H (1 pc.).
Fit the holes of the screws removed in step 1) with the screw
holes of the positioning plate, and fix it with the three fixing
screws C.
3) Install the button cover with the lock button fixing screws D (2
pcs.) to hide the lock button on the top of the punch cover.
