1-37
BEFORE USING THE MACHINE
Specifications
4
Gently push the paper tray into the
machine.
Push the tray firmly all the way into the machine.
If you loaded a different type of paper than was loaded previously, be sure to change the paper type setting in "Paper
Tray Settings" in the system settings.
Do not place heavy objects on the tray or press down on the tray.
System Settings: Paper Tray Settings (page 7-13)
Change these settings if you have loaded a different type of paper in the tray.
Name Large capacity tray (MX-LC10)
Paper size 8-1/2" x 11" (A4)
Paper weight 16 to 28 lbs. (60 to 105 g/m
2
)
Paper capacity (plain) 3500 sheets (20 lbs. (80 /m
2
))
Dimensions 14-39/64" (W) x 22-19/32" (D) x 20-15/32" (H)
(371 mm (W) x 574 mm (D) x 520 mm (H))
Power supply Supplied from the main unit
Weight Approximately 64 lbs. (29 kg)
Overall dimensions when attached to
machine
43-17/64" (W) x 26-57/64" (D)
(1099 mm (W) x 683 mm (D))
To Next Page
