1-52
BEFORE USING THE MACHINE
* For index paper, equivalent to 140-lbs.
* For index paper, equivalent to 140-lbs.
Specifications are subject to change for improvement without notice.
Supplies
The finisher and saddle stitch finisher require the following staple cartridge:
Staple cartridge for finisher and
saddle stitch finisher (approx. 5,000
per cartridge X 3 cartridges)
SF-SC11
Staple cartridge for saddle stitch
finisher (approx. 2000 per cartridge X
3 cartridges)
AR-SC3
STAPLE CARTRIDGE REPLACEMENT AND STAPLE
JAM REMOVAL
When a finisher is installed, a message will appear when the staple cartridge runs out of staples or a staple jam occurs.
Follow the procedure below to replace the staple cartridge or remove jammed staples.
Dimensions When tray is folded up: 27-9/16" (W) x 24-13/16" (D) x 45-9/32" (H)
(700 mm (W) x 630 mm (D) x1150 mm(H))
When tray is extended: 32" (W) x 24-13/16" (D) x 45-9/32" (H)
(813 mm (W) x 630 mm (D) x1150 mm(H))
Not including stopper (1-37/64" (40 mm)) when attached to machine
Weight Approx. 119 lbs. (Approx. 54 kg) Approx. 165
lbs.
(Approx. 75 kg)
Overall dimensions when
attached to machine
75-15/16" (W) x 24-13/16" (D) (Separation from machine 15-3/4")
(1904 mm (W) x 630 mm (D) (Separation from machine 400 mm))
Name Punch module (AR-PN4B)
Hole punching 3 holes
Allowed paper sizes for
punching
11" x 17", 8-1/2" x 14", 8-1/2" x 13", 8-1/2" x 11", 8-1/2" x 11"R, A3, B4, A4, A4R, B5, B5R
Page weight 15 to 68* lbs. (56 to 256 g/m
2
)
Power supply Supplied from finisher / saddle stitch finisher
Dimensions 3-3/4" (W) x 22-1/16" (D) x 6-45/64" (H) (95 mm (W) x 560 mm (D) x 170 mm (H))
Weight Approx. 7.8 lbs. (Approx. 3.5 kg)
• The following papers cannot be stapled and punched:
Special papers such as transparency film and label sheets
• If mixed paper sizes are selected for stapling jobs, stapling will be automatically canceled.
To Next Page
