Command list
Sending
command
Function Sending
example
Response command Reception example
pwr#on Sets AC OUT to on.
L
F01.02.pwr#on.82
C
R No reply No reply
pwr#of Sets AC OUT to off.
L
F01.02.pwr#of.7A
C
R No reply No reply
reqps Requests the state of
AC OUT.
L
F01.02.reqps.54
C
R ps:on AC OUT is on.
L
F02.01.ps:on.23
C
R
ps:of AC OUT is off.
L
F02.01.ps:of.1B
C
R
ps:wa AC OUT delayed switch on
L
F02.01.ps:wa.1E
C
R
reqcm Requests the operating
mode.
L
F01.02.reqcm.41
C
R cm:rem Operating in the remote mode.
L
F02.01.cm:rem.77
C
R
cm:loc Operating in the local mode.
L
F02.01.cm:loc.71
C
R
reqst Requests the state of
the device.
L
F01.02.reqst.58
C
R ds:ok Operates normally.
L
F02.01.ds:ok.14
C
R
ds:er Error
L
F02.01.ds:er.11
C
R
requsv Requests the voltage of
the DC power.
L
F01.02.requsv.CF
C
R usv:IIIDD
III = Integer part of the voltage value (3
digits)
DD = Decimal part of the voltage value (2
digits)
L
F02.01.usv:01250.B9
C
R
usv:01250 = 12.50 V
requss Requests the state of
the DC power.
L
F01.02.requss.CC
C
R uss:ok Within the normal voltage range
L
F02.01.uss:ok.98
C
R
uss:er Voltage detection error
L
F02.01.uss:er.95
C
R
uss:ov Voltage error (high voltage)
L
F02.01.uss:ov.A3
C
R
uss:lo Voltage error (low voltage)
L
F02.01.uss:lo.99
C
R
reqt1v Requests the
temperature.
L
F01.02.reqt1v.8C
C
R t1v:SIIIDD
S = Sign (+ or -)
III = Integer part of the temperature value
(3 digits)
DD = Decimal part of the temperature
value (2 digits)
L
F02.01.t1v:+031.25.A4
C
R
t1v:+031.25 = 31.25°C
reqt1s Requests the
temperature state.
L
F01.02.reqt1s.89
C
R t1s:ok Within the normal temperature
range
L
F02.01.t1s:ok.55
C
R
t1s:er Temperature sensor error
L
F02.01.t1s:er.52
C
R
t1s:ov Temperature error (high
temperature)
L
F02.01.t1s:ov.60
C
R
reqrt Request the total time
with AC OUT on.
L
F01.02.reqrt.57
C
R rt:HHHHHH
HHHHHH = The number of hours
expressed as a 6-digit hexadecimal
number
L
F02.01.rt:000100.6A
C
R
rt:000100 = 256 hours
rt:002710 = 10000 hours
reqsv Requests the software
version.
L
F01.02.reqsv.5A
C
R sv:XXX
XXX = software version (3 digits)
L
F02.01.sv:001.DD
C
R
sv:001 = version 001
reqhv Requests the hardware
version.
L
F01.02.reqhv.4F
C
R hv:AAA_BBB_CCC
AAA = Hardware index (3 digits)
BBB = Hardware version (3 digits)
CCC = Production key (3 digits)
L
F02.01.hv:05c_002_001.CA
C
R
reqhn Requests the model
name.
L
F01.02.reqhn.47
C
R hn:LED-RPS-CL-R
L
F02.01.hn:LED-RPS-CL-R.6B
C
R
