11
Explanations About Operations
(1) AC OUT control and operation after turning the devices on
ON/OFF
(LE
D indicator)
Control in
DC12V
Open(off)
Low(on)
off
on
AC(L) OUT
ps#on
0V
12V
0sec 30sec
off flashing ON
off
on
RS- 485
AC OUT turns on 30 seconds after the
devices have been turned on when AC
OUT is set to on using Control in or RS-
485 within 30 seconds after turning the
devices on.
In such a case, the ON/OFF LED
indicator flashes.
ON/OFF
(LE
D indicator)
Control in
DC12V
Open(off)
Low(on)
off
on
AC(L) OUT
ps#on
0V
12V
0sec 30sec
off ON
off
on
RS- 485
AC OUT turns on immediately when AC
OUT is set to on using Control in or RS-
485 after 30 seconds have passed after
turning the devices on.
(2) AC OUT control and operation
0sec 30sec
ps#on ps#of ps#on
flashingonoff off ON
ON/OFF
(LE
D indicator)
Control in
DC12V
Open(off)
Low(on)
off
on
AC(L) OUT
0V
12V
off
on
RS- 485
When AC OUT was turned on within 30
seconds after AC OUT had been set
to on using Control in or RS-485, AC
OUT turns on 30 seconds after AC OUT
previously turned on.
In such a case, the ON/OFF LED
indicator flashes.
