AC OUT turns on immediately when
AC OUT was turned on more than 30
seconds after AC OUT had been set to
on using Control in or RS-485.
(3) Timing of Control out output
Low(on)
Hi-Z(off)
Con
trol out
ps#on ps#of
1.8sec
Co
ntrol in
DC12V
Open(off)
Low(on)
0V
12V
RS- 485
Control out turns on 1.8 seconds after
AC OUT is set to on using Control in or
RS-485.
Control out turns immediately off when
AC OUT is set to off using Control in or
RS-485.
(4) Operation when an error occurs
High-temperature protection operation
AC OUT turns off when the
internal temperature reaches
60°C or higher and AC OUT
turns on again when the internal
temperature decreases to 55°C
or lower.
High-voltage protection operation
AC OUT turns off when the
voltage reaches 14 V or higher
and AC OUT turns on again when
the voltage decreases to 13.5 V
or lower.
Low-voltage protection operation
AC OUT turns off when the
voltage decreases to 10 V or
lower and AC OUT turns on again
when the voltage increases to
10.5 V or higher.
